- Vortex ring launcher, 10 m reach
- RGB 3-in-1 LED colorful rings
- Show-ready in ~1 min 50 s
- DMX512 + LCD control board
MODEL X-R2
Swirl Confetti Fan
A Swirl Confetti Fan with 100 W power, DMX-512 control, 8 kg net weight.
- Input voltage220–240 V,50/60 Hz
- Breaker typeFuse (F)
- CurrentLimiterSpecifications1A, 250 V
- Total power consumption100 W
- PowerInputConnectorLockable PowerCon
- PowerOutputConnectorLockable PowerCon
- ConfettiCapacityAppr: 1.5 kg
- Max CoverageApprox. 80㎡ (hang 10m high)
- Maximum Continuous Duration @ full volumeAppr 3–5 min
- On-device control7-segdigital display
- Wireless controlX
- Control protocolDMX-512
- DMXChannel Range1
- PowerCordNo
- Wireless ControllerModelNo
- ConsumableConfetti
- Net weight8 kg
- Gross weight10 kg
- Machine dimensions445x445x367.7mm
- Packing dimensions525x525 x420 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
X-R2 datasheet
| Model | X-R2 |
| Input voltage | 220–240 V,50/60 Hz |
| Breaker type | Fuse (F) |
| CurrentLimiterSpecifications | 1A, 250 V |
| Total power consumption | 100 W |
| ConfettiCapacity | Appr: 1.5 kg |
| Max Coverage | Approx. 80㎡ (hang 10m high) |
| Maximum Continuous Duration @ full volume | Appr 3–5 min |
| PowerCord | No |
| Consumable | Confetti |
| Machine dimensions | 445x445x367.7mm |
| PowerInputConnector | Lockable PowerCon |
| PowerOutputConnector | Lockable PowerCon |
| On-device control | 7-segdigital display |
| Wireless control | X |
| Control protocol | DMX-512 |
| DMXChannel Range | 1 |
| Wireless ControllerModel | No |
| Net weight | 8 kg |
| Gross weight | 10 kg |
| Packing dimensions | 525x525 x420 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against X-R2. Full datasheets are one click away.
| Specification |  X-R2This model | H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V,50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
Features
What the X-R2 does on your stage
Fan system
Power fan and innovative wind guide structure.
Large confetti capacity can
Large confetti capacity can hold 1.5KG confetti.
Confetti scattering time for 3-5
Confetti scattering time for 3-5 minutes with wide coverage.
Confetti is scattered evenly
Confetti is scattered evenly and covers a wide area.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
X-R2 — quick answers
What voltage does the X-R2 require?
The Swirl Confetti Fan accepts 220–240 V,50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the X-R2 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the X-R2?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
