MODEL H-1 PLUS
2-in-1 Moving-Head Fog Jet
A 2-in-1 moving-head fog jet that fires 29,000 ft³/min through a 24 × 5 W RGBA beam.
- TypeMoving head super-jet fog machine
- LED source24 × 5 W, RGBA
- Total power consumption1,500 W
- Input voltage220–240 V, 50/60 Hz
- Current limiterBreaker, 8 A, 250 V
- Power connectorLockable PowerCon
- Heat-up timeApprox. 9.5 min
- Max output volumeApprox. 29,000 ft³/min
- Max output distanceApprox. 6–8 m
- Fluid consumptionApprox. 6.8 min/L @ full volume
- Max continuous outputApprox. 6 s @ full volume
- Fluid tank capacity1.3 L / 0.3 Gal.
- ConsumablePRO-A or PRO-V fog fluid
- ThermostatPhysical + electronic thermo-control
- Safety featuresAdjustable output, no-fluid protection, instant stop
- Control protocolDMX-512, 10 channels
- On-device controlLCD control board
- Data connectors3-pin and 5-pin XLR
- AccessoriesPower cord included
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
H-1 PLUS datasheet
| Model | H-1 PLUS |
| Type | Moving head super-jet fog machine |
| LED source | 24 × 5 W, RGBA |
| Total power consumption | 1,500 W |
| Input voltage | 220–240 V, 50/60 Hz |
| Current limiter | Breaker, 8 A, 250 V |
| Heat-up time | Approx. 9.5 min |
| Max output volume | Approx. 29,000 ft³/min |
| Max output distance | Approx. 6–8 m |
| Fluid consumption | Approx. 6.8 min/L @ full volume |
| Max continuous output | Approx. 6 s @ full volume |
| Fluid tank capacity | 1.3 L / 0.3 Gal. |
| Consumable | PRO-A or PRO-V fog fluid |
| Thermostat | Physical + electronic thermo-control |
| Power connector | Lockable PowerCon |
| Safety features | Adjustable output, no-fluid protection, instant stop |
| Control protocol | DMX-512, 10 channels |
| On-device control | LCD control board |
| Data connectors | 3-pin and 5-pin XLR |
| Accessories | Power cord included |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against H-1 PLUS. Full datasheets are one click away.
| Specification | H-1 PLUSThis model |  H-K1Pro Auto Smoke Ring Machine |  DHZ-670Oil-Based Haze Machine |
|---|---|---|---|
| Type | Moving head super-jet fog machine | Auto smoke ring machine | Oil-based haze machine |
| Light source | 24 × 5 W, RGBA | RGB 3-in-1 LED ring | — |
| Control protocol | DMX-512, 10 channels | DMX512, 3 channels | DMX-512, 2 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the H-1 PLUS does on your stage
Fog meets light
A super-jet fog output and a 24 × 5 W RGBA moving beam combine in one fixture for dynamic aerial looks.
Room-filling blast
Approx. 29,000 ft³/min output with 6–8 m reach cuts through clubs and stages.
Full protection suite
Physical thermostat, electronic thermo-control, no-fluid protection and instant stop built in.
Desk friendly
DMX-512 with 10 channels on 3/5-pin XLR, plus an LCD board for manual runs.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
What arrives with H-1 PLUS
- Power cord
- Export-grade carton with foam inserts
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
H-1 PLUS — quick answers
What voltage does the H-1 PLUS require?
The 2-in-1 Moving-Head Fog Jet accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the H-1 PLUS with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the H-1 PLUS?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
