- Vortex ring launcher, 10 m reach
- RGB 3-in-1 LED colorful rings
- Show-ready in ~1 min 50 s
- DMX512 + LCD control board
MODEL DHZ-670
Oil-Based Haze Machine
An oil-based haze machine with instant start and unlimited output that makes every beam visible.
- TypeOil-based haze machine
- Total power consumption500 W
- Input voltage220–240 V, 50/60 Hz
- Current draw2.2 A
- Current limiterFuse (F), 5 A, 250 V
- Power connectorIEC
- Heat-up timeNone (instant start)
- Max output volumeApprox. 3,200 ft³/min
- Fluid consumptionApprox. 25 h/L @ full volume
- Continuous outputUnlimited @ 100% level
- Cumulative outputApprox. 3,750 min per full tank
- Fluid tank capacity2.5 L
- ConsumablePRO-H1L oil-based haze fluid
- Fan speedAdjustable
- Control protocolDMX-512, 2 channels
- On-device controlLCD control board
- Data connectors3-pin XLR
- AccessoriesFlight case and power cord included
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
DHZ-670 datasheet
| Model | DHZ-670 |
| Type | Oil-based haze machine |
| Total power consumption | 500 W |
| Input voltage | 220–240 V, 50/60 Hz |
| Current draw | 2.2 A |
| Current limiter | Fuse (F), 5 A, 250 V |
| Heat-up time | None (instant start) |
| Max output volume | Approx. 3,200 ft³/min |
| Fluid consumption | Approx. 25 h/L @ full volume |
| Continuous output | Unlimited @ 100% level |
| Cumulative output | Approx. 3,750 min per full tank |
| Fluid tank capacity | 2.5 L |
| Consumable | PRO-H1L oil-based haze fluid |
| Fan speed | Adjustable |
| Power connector | IEC |
| Control protocol | DMX-512, 2 channels |
| On-device control | LCD control board |
| Data connectors | 3-pin XLR |
| Accessories | Flight case and power cord included |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against DHZ-670. Full datasheets are one click away.
| Specification |  DHZ-670This model | H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | Oil-based haze machine | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512, 2 channels | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
Features
What the DHZ-670 does on your stage
Beam-ready atmosphere
Fine, even haze gives lasers and beam lights a crisp medium with clearly defined outlines.
Always ready
No heat-up time — start on demand and run unlimited continuous output at 100%.
Frugal fluid use
Approx. 25 hours of output per litre; one 2.5 L tank lasts about 3,750 show minutes.
Touring package
Ships with a flight case; 3-pin XLR DMX and an LCD board keep operation simple.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
What arrives with DHZ-670
- Flight case
- Power cord
- Export-grade carton with foam inserts
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
DHZ-670 — quick answers
What voltage does the DHZ-670 require?
The Oil-Based Haze Machine accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the DHZ-670 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the DHZ-670?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
