MODEL DC-3L
50W Confetti Shot
A 50W Confetti Shot with 30 m output height, DMX512 2-channel control, 51 kg net weight.
- Input voltageAC 100 V-240 V 50/60 HZ
- Total power consumption50W
- Power Input ConnectorLockable PowerCon
- Power Output ConnectorLockable PowerCon
- Confetti Shot Barrel Capacity2.5 L
- Water Cannon Barrel Capacity10 L
- Gas Tank Capacity20 L
- Max output heightApprox. 30 m
- On-device control7-seg digital display
- Wireless controlNo
- Control protocolDMX-512
- DMX channels2
- Data Connectors3- and 5-pin XLR
- Flight CaseYes
- Power CordYes
- Wireless Controller ModelNo
- ConsumableConfetti Paper(except Electri confetti), Streamer
- Net weight51 kg
- Gross weight52.5 kg
- Machine dimensions650 × 580 × 605 mm
- Packing dimensions692 × 557 × 520 mm
- Net Weight of Water Cannon Barrel5.6 kg
- Gross Weight of Water Cannon Barrel7.4 kg
- Water Cannon Barrel Dimensions1130 × 133 × 221 mm
- Water Cannon Barrel Packing Dimensions1250 ×274 × 197 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
DC-3L datasheet
| Model | DC-3L |
| Input voltage | AC 100 V-240 V 50/60 HZ |
| Total power consumption | 50W |
| Confetti Shot Barrel Capacity | 2.5 L |
| Water Cannon Barrel Capacity | 10 L |
| Gas Tank Capacity | 20 L |
| Max output height | Approx. 30 m |
| Flight Case | Yes |
| Power Cord | Yes |
| Consumable | Confetti Paper(except Electri confetti), Streamer |
| Machine dimensions | 650 × 580 × 605 mm |
| Water Cannon Barrel Dimensions | 1130 × 133 × 221 mm |
| Power Input Connector | Lockable PowerCon |
| Power Output Connector | Lockable PowerCon |
| On-device control | 7-seg digital display |
| Wireless control | No |
| Control protocol | DMX-512 |
| DMX channels | 2 |
| Data Connectors | 3- and 5-pin XLR |
| Wireless Controller Model | No |
| Net weight | 51 kg |
| Gross weight | 52.5 kg |
| Packing dimensions | 692 × 557 × 520 mm |
| Net Weight of Water Cannon Barrel | 5.6 kg |
| Gross Weight of Water Cannon Barrel | 7.4 kg |
| Water Cannon Barrel Packing Dimensions | 1250 ×274 × 197 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against DC-3L. Full datasheets are one click away.
| Specification |  DC-3LThis model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | AC 100 V-240 V 50/60 HZ | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the DC-3L does on your stage
Dual-functional design: optional confetti
Dual-functional design: optional confetti cannon or water cannon to meet the needs of different scenes.
Large pressure tank with 20L
Large pressure tank with 20L capacity, sturdy and durable.
Excellent workmanship, safe and reliable
Excellent workmanship, safe and reliable.
Spray angle
Adjustable spraying angle with maximum vertical range of 30 m.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
DC-3L — quick answers
What voltage does the DC-3L require?
The 50W Confetti Shot accepts AC 100 V-240 V 50/60 HZ. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the DC-3L with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the DC-3L?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
