MODEL H-SF800
Water Mist Flamer
A water-based flamer with 192 W LED fire glow. The safe flame effect for stages, theme parks and cultural sites.
- TypeWater mist flamer
- EffectWater mist flame column
- Total power consumption800 W
- Atomizer power300 W × 2
- Input voltageAC 110–240 V, 50/60 Hz
- LED source64 × 3 W, 192 W total
- Max continuous outputApprox. 210 min
- Flame concentrationHigh / Low
- Flame volume1–100
- Flame luminanceOff, 1–100
- Flame height1–11
- Control protocolDMX-512, 4 channels
- RDM supportYes
- Main water tankApprox. 14 L
- Adjustable water tankApprox. 3.5 L
- ConsumablePlain water
- RatingIP55 outdoor
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
H-SF800 datasheet
| Model | H-SF800 |
| Type | Water mist flamer |
| Effect | Water mist flame column |
| Total power consumption | 800 W |
| Atomizer power | 300 W × 2 |
| Input voltage | AC 110–240 V, 50/60 Hz |
| LED source | 64 × 3 W, 192 W total |
| Max continuous output | Approx. 210 min |
| Flame concentration | High / Low |
| Flame volume | 1–100 |
| Flame luminance | Off, 1–100 |
| Flame height | 1–11 |
| RDM support | Yes |
| Main water tank | Approx. 14 L |
| Adjustable water tank | Approx. 3.5 L |
| Consumable | Plain water |
| Control protocol | DMX-512, 4 channels |
| Rating | IP55 outdoor |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against H-SF800. Full datasheets are one click away.
| Specification | H-SF800This model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | Water mist flamer | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | 64 × 3 W, 192 W total | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512, 4 channels | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | AC 110–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
| Rating | IP55 outdoor | — | — |
See it in action
Product demo
Features
What the H-SF800 does on your stage
Fire look, zero fire
A water-mist column lit by 192 W of LED delivers the flame visual with no fuel and no fire hazard.
Safe indoors and out
IP55 housing and plain-water consumable make it a drop-in for theme parks, stages and cultural sites.
Full DMX control
Height, volume, luminance and concentration are all programmable over DMX-512 / RDM.
Long shows per fill
The approx. 14 L main tank runs up to 210 minutes of continuous effect.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
H-SF800 — quick answers
What voltage does the H-SF800 require?
The Water Mist Flamer accepts AC 110–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the H-SF800 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the H-SF800?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
