Product demo
MODEL HF-P5
Pyrostorm 5
A Pyrostorm 5 with 2,000 W power, 8–10 m (no wind condition) output height, DMX512 6-channel control.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeBreaker
- Breaker10 A, 250 V
- Total power consumption2,000 W
- Max output heightApprox. 8–10 m (no wind condition)
- Fluid Consumption RateApprox. 0.32 min/L
- Fluid tank capacity30 L
- Wireless controlNo
- Manual ControlLCD control panel
- Wired controlYes
- DMX channels6
- Isopar-g
- Net weight76 kg
- Gross weight78 kg
- Machine dimensions695× 535× 426mm
- Flight case Dimensions794 × 565 × 608mm
- Packing dimensions800× 580× 525mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
HF-P5 datasheet
| Model | HF-P5 |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Breaker |
| Breaker | 10 A, 250 V |
| Total power consumption | 2,000 W |
| Max output height | Approx. 8–10 m (no wind condition) |
| Fluid Consumption Rate | Approx. 0.32 min/L |
| Fluid tank capacity | 30 L |
| Isopar-g | |
| Machine dimensions | 695× 535× 426mm |
| Flight case Dimensions | 794 × 565 × 608mm |
| Wireless control | No |
| Manual Control | LCD control panel |
| Wired control | Yes |
| DMX channels | 6 |
| Net weight | 76 kg |
| Gross weight | 78 kg |
| Packing dimensions | 800× 580× 525mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against HF-P5. Full datasheets are one click away.
| Specification |  HF-P5This model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | — | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the HF-P5 does on your stage
Stainless steel body, waterproof
Stainless steel body, waterproof structure design, IPX3 waterproof rate.
Safety protection
The unique safety lock design, prevent false triggering.
Control
Intelligent electronic control system alarm function, safe and reliable.
Integrated valve group design
Integrated valve group design and imported injection valve, more stable for using.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
HF-P5 — quick answers
What voltage does the HF-P5 require?
The Pyrostorm 5 accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the HF-P5 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the HF-P5?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
