MODEL X-R1
Automatic Confetti Machine
An Automatic Confetti Machine with 1,100 W power, 15m throw, 15 m output height.
- Input voltageAC 220–240 V, 50/60 Hz
- Breaker typeBreaker
- Total power consumption1,100 W
- Max output heightApprox. 15 m
- Max output distanceApprox. 15m
- Max CoverageApprox. 200 ㎡
- Maximum Continuous Duration @ full volumeApprox. 150 sec
- On-device controlLCD control board
- Wireless controlNo
- Control protocolDMX-512
- DMX channels1 or 2-F or 2-M ( 3 DMX Channel Modes)
- Data Connectors3- and 5-pin XLR
- Flight CaseYes
- Power CordYes
- Wireless Controller ModelNo
- ConsumableConfetti
- Net weight77 kg
- Gross weight80.3 kg
- Machine dimensions844 × 520 × 808.4 mm
- Packing dimensions884 × 560 × 772 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
X-R1 datasheet
| Model | X-R1 |
| Input voltage | AC 220–240 V, 50/60 Hz |
| Breaker type | Breaker |
| Total power consumption | 1,100 W |
| Max output height | Approx. 15 m |
| Max output distance | Approx. 15m |
| Max Coverage | Approx. 200 ㎡ |
| Maximum Continuous Duration @ full volume | Approx. 150 sec |
| Flight Case | Yes |
| Power Cord | Yes |
| Consumable | Confetti |
| Machine dimensions | 844 × 520 × 808.4 mm |
| On-device control | LCD control board |
| Wireless control | No |
| Control protocol | DMX-512 |
| DMX channels | 1 or 2-F or 2-M ( 3 DMX Channel Modes) |
| Data Connectors | 3- and 5-pin XLR |
| Wireless Controller Model | No |
| Net weight | 77 kg |
| Gross weight | 80.3 kg |
| Packing dimensions | 884 × 560 × 772 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against X-R1. Full datasheets are one click away.
| Specification |  X-R1This model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | AC 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the X-R1 does on your stage
Output performance
With unique “Paper Conveying” patent technology enables smooth and even output.
LED lighting
Integrated-designed with flight case, convenient for transport.
Large confetti capacity can
Large confetti capacity can hold 40L confetti, more convenient to use.
DMX control
With DMX control to adjust confetti output.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
X-R1 — quick answers
What voltage does the X-R1 require?
The Automatic Confetti Machine accepts AC 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the X-R1 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the X-R1?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
