Product demo
MODEL X-4 LED
LED CO2 Jet
A LED CO2 Jet with 160 W power, 8 m output height, DMX512 7-channel control.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeFuse (F)
- Breaker2 A, 250 V
- Total power consumption160 W
- Operating Current0.7
- Power Input ConnectorLockable PowerCon
- LED colorRGB
- LED typeSingle Color
- Power per LED5 W
- LED quantity27 pcs
- Quantity of red9 pcs
- Quantity of green9 pcs
- Quantity of blue9 pcs
- Adjustable outputNo
- Volume Adjustment Level/Range90 °
- Max output heightApprox. 8 m
- On-device control7-seg digital display
- Wired controlNo
- Control protocolDMX-512
- DMX channels7
- Data Connectors3-pin XLR
- Power CordYes
- Wired Controller ModelNo
- CO2 CylinderOptional
- ConsumableLiquid carbon dioxide
- Net weight9.3 kg
- Gross weight10.6 kg
- Machine dimensions273.5 × 286.1 × 399 mm
- Packing dimensions475 × 355 × 370 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
X-4 LED datasheet
| Model | X-4 LED |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Fuse (F) |
| Breaker | 2 A, 250 V |
| Total power consumption | 160 W |
| LED type | Single Color |
| Power per LED | 5 W |
| LED quantity | 27 pcs |
| Quantity of red | 9 pcs |
| Quantity of green | 9 pcs |
| Quantity of blue | 9 pcs |
| Adjustable output | No |
| Volume Adjustment Level/Range | 90 ° |
| Max output height | Approx. 8 m |
| Power Cord | Yes |
| CO2 Cylinder | Optional |
| Consumable | Liquid carbon dioxide |
| Machine dimensions | 273.5 × 286.1 × 399 mm |
| LED color | RGB |
| Power Input Connector | Lockable PowerCon |
| On-device control | 7-seg digital display |
| Wired control | No |
| Control protocol | DMX-512 |
| DMX channels | 7 |
| Data Connectors | 3-pin XLR |
| Wired Controller Model | No |
| Operating Current | 0.7 |
| Net weight | 9.3 kg |
| Gross weight | 10.6 kg |
| Packing dimensions | 475 × 355 × 370 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against X-4 LED. Full datasheets are one click away.
| Specification |  X-4 LEDThis model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the X-4 LED does on your stage
Quality durable magnetic valve
Quality durable magnetic valve.
Stable and strong anti-interference
Stable and strong anti-interference ability.
LED lighting
Small and light for each unit with unique low noise design.
Power
Powerful atmospheric column reaches 8 meters.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
X-4 LED — quick answers
What voltage does the X-4 LED require?
The LED CO2 Jet accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the X-4 LED with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the X-4 LED?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
