- Vortex ring launcher, 10 m reach
- RGB 3-in-1 LED colorful rings
- Show-ready in ~1 min 50 s
- DMX512 + LCD control board
MODEL WP-4L
1,400 W Fog Balloon
A 1,400 W Fog Balloon with 4,500 cuft/min output, 3.5 m throw, 4 m output height.
- Input voltage220–240V, 50/60Hz
- Breaker typeBreaker
- Breaker8 A, 250 V
- Total power consumption1,400 W
- Heat-up timeApprox. 4 min
- Bubble fluid tank capacity9 L
- Fog fluid tank capacity5 L
- Adjustable outputYes
- Max output volumeApprox. 4,500 cuft/min
- Max output heightApprox. 4 m
- Max output distanceApprox. 3.5 m
- Fog fluid consumptionApprox. 91 min/L
- Bubble fluid consumptionApprox. 12.5 min/L
- On-device controlDigital Display LCD Control Panel
- Wireless controlNo
- Wired controlNo
- Control protocolDMX512
- DMX channels12
- LED colorRGBY
- LED typeFour in one
- Power per LED8 W
- LED quantity8 pcs
- Total Power of LED64W
- ConsumablePRO-PW and PRO-C or PRO-J
- Net weight26 kg
- Gross weight27.2 kg
- Machine dimensions485 × 425 × 523 mm
- Packing dimensions580 × 535 × 570 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
WP-4L datasheet
| Model | WP-4L |
| Input voltage | 220–240V, 50/60Hz |
| Breaker type | Breaker |
| Breaker | 8 A, 250 V |
| Total power consumption | 1,400 W |
| Heat-up time | Approx. 4 min |
| Bubble fluid tank capacity | 9 L |
| Fog fluid tank capacity | 5 L |
| Adjustable output | Yes |
| Max output volume | Approx. 4,500 cuft/min |
| Max output height | Approx. 4 m |
| Max output distance | Approx. 3.5 m |
| Fog fluid consumption | Approx. 91 min/L |
| Bubble fluid consumption | Approx. 12.5 min/L |
| LED type | Four in one |
| Power per LED | 8 W |
| LED quantity | 8 pcs |
| Total Power of LED | 64W |
| Consumable | PRO-PW and PRO-C or PRO-J |
| Machine dimensions | 485 × 425 × 523 mm |
| LED color | RGBY |
| On-device control | Digital Display LCD Control Panel |
| Wireless control | No |
| Wired control | No |
| Control protocol | DMX512 |
| DMX channels | 12 |
| Net weight | 26 kg |
| Gross weight | 27.2 kg |
| Packing dimensions | 580 × 535 × 570 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against WP-4L. Full datasheets are one click away.
| Specification |  WP-4LThis model | H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240V, 50/60Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
Features
What the WP-4L does on your stage
Jet design
Jet design, produce perfect bubble fog, greatly reduces the formation of excess haze.
Heating system
Well-design heating system releases the fog evenly and purely, no fluid dropping off.
Fan system
Four fans make the bubble fog fly higher and further.
LED lighting
Combining with LED light, it perfectly integrates with the fog bubble effect,making the effect more beautiful.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
WP-4L — quick answers
What voltage does the WP-4L require?
The 1,400 W Fog Balloon accepts 220–240V, 50/60Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the WP-4L with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the WP-4L?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
