Product demo
MODEL WP-4
Pro Bubble Fog Machine
A Pro Bubble Fog Machine with 1,600 W power, 6,000 cuft/min output, 10 m throw.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeBreaker
- Breaker8 A, 250 V
- Total power consumption1,600 W
- Power Input ConnectorLockable PowerCon
- Power Output ConnectorLockable PowerCon
- Heat-up timeApprox. 3.5 min
- Adjustable outputYes
- Max output volumeApprox. 6,000 cuft/min
- Max output heightApprox. 10 m
- Max output distanceApprox. 10 m
- Haze Fluid Consumption RateApprox. 90.9 min/L
- Bubble Fluid Consumption RateApprox. 12.5 min/L
- Haze Fluid Tank Capacity5 L
- Bubble fluid tank capacity9 L
- ConsumablePRO-PW & PRO-C or PRO-J
- On-device controlLCD Control Board
- Wireless controlNo
- Wired controlNo
- Control protocolDMX-512
- DMX channels4
- Data Connectors3-pin and 5-pin XLR
- Power CordYes
- Wireless Controller ModelNo
- Net weight45.4 kg
- Gross weight51.4 kg
- Machine dimensions532 × 470 × 557 mm
- Packing dimensions730 × 590 × 640 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
WP-4 datasheet
| Model | WP-4 |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Breaker |
| Breaker | 8 A, 250 V |
| Total power consumption | 1,600 W |
| Heat-up time | Approx. 3.5 min |
| Adjustable output | Yes |
| Max output volume | Approx. 6,000 cuft/min |
| Max output height | Approx. 10 m |
| Max output distance | Approx. 10 m |
| Haze Fluid Consumption Rate | Approx. 90.9 min/L |
| Bubble Fluid Consumption Rate | Approx. 12.5 min/L |
| Haze Fluid Tank Capacity | 5 L |
| Bubble fluid tank capacity | 9 L |
| Consumable | PRO-PW & PRO-C or PRO-J |
| Power Cord | Yes |
| Machine dimensions | 532 × 470 × 557 mm |
| Power Input Connector | Lockable PowerCon |
| Power Output Connector | Lockable PowerCon |
| On-device control | LCD Control Board |
| Wireless control | No |
| Wired control | No |
| Control protocol | DMX-512 |
| DMX channels | 4 |
| Data Connectors | 3-pin and 5-pin XLR |
| Wireless Controller Model | No |
| Net weight | 45.4 kg |
| Gross weight | 51.4 kg |
| Packing dimensions | 730 × 590 × 640 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against WP-4. Full datasheets are one click away.
| Specification |  WP-4This model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the WP-4 does on your stage
Jet design
Innovative Jet design, create massive amount of fog filled bubbles.
Heating system
Well-designed heating system releases the fog evenly and purely, no fluid dropping off.
Fan system
Three fans with adjustable angles make the fog bubble fly higher, further.
DMX control
Built-in LCD control, 3-pin and 5-pin DMX control, easy to use.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
WP-4 — quick answers
What voltage does the WP-4 require?
The Pro Bubble Fog Machine accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the WP-4 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the WP-4?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
