MODEL WP-2
650 W Bubble Fog Machine
A 650 W Bubble Fog Machine with 4,500 cuft/min output, Bubble 7.2 m, Bubble Fog 5.8 m throw, Bubble 6.5 m, Bubble Fog 4 m output height.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeBreaker
- Breaker6 A, 250 V
- Total power consumption650 W
- Power Input ConnectorLockable PowerCon
- Power Output ConnectorLockable PowerCon
- Power CordYes
- Omega BracketYes
- Wireless Controller ModelW-2
- Heat-up timeApprox. 3 min
- Heater TypeAluminum Heater Block
- LED colorRGBY
- LED typeQuad-Color
- Power per LED8 W
- LED quantity6 pcs
- Total Power of LED48 W
- Haze Fluid Tank Capacity1.3 L
- Bubble fluid tank capacity1.3 L
- Adjustable outputYes
- Max output volumeApprox. 4,500 cuft/min
- Max output heightBubble Approx. 6.5 m, Bubble Fog Approx. 4 m
- Max output distanceBubble Approx. 7.2 m, Bubble Fog Approx. 5.8 m
- Haze Fluid Consumption RateApprox. 60 min/L
- Bubble Fluid Consumption RateApprox. 40 min/L
- On-device controlLCD control board
- Wireless controlW-2
- Wired controlNo
- Control protocolDMX-512
- DMX channels12
- Data Connectors3- and 5-pin XLR
- ConsumablePRO-PW and PRO-C or PRO-J
- Net weight13.7kg
- Gross weight16.3 kg
- Machine dimensions422 × 317 × 418.3 mm
- Packing dimensions535 × 435 × 500 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
WP-2 datasheet
| Model | WP-2 |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Breaker |
| Breaker | 6 A, 250 V |
| Total power consumption | 650 W |
| Power Cord | Yes |
| Omega Bracket | Yes |
| Heat-up time | Approx. 3 min |
| Heater Type | Aluminum Heater Block |
| LED type | Quad-Color |
| Power per LED | 8 W |
| LED quantity | 6 pcs |
| Total Power of LED | 48 W |
| Haze Fluid Tank Capacity | 1.3 L |
| Bubble fluid tank capacity | 1.3 L |
| Adjustable output | Yes |
| Max output volume | Approx. 4,500 cuft/min |
| Max output height | Bubble Approx. 6.5 m, Bubble Fog Approx. 4 m |
| Max output distance | Bubble Approx. 7.2 m, Bubble Fog Approx. 5.8 m |
| Haze Fluid Consumption Rate | Approx. 60 min/L |
| Bubble Fluid Consumption Rate | Approx. 40 min/L |
| Consumable | PRO-PW and PRO-C or PRO-J |
| Machine dimensions | 422 × 317 × 418.3 mm |
| LED color | RGBY |
| Power Input Connector | Lockable PowerCon |
| Power Output Connector | Lockable PowerCon |
| Wireless Controller Model | W-2 |
| On-device control | LCD control board |
| Wireless control | W-2 |
| Wired control | No |
| Control protocol | DMX-512 |
| DMX channels | 12 |
| Data Connectors | 3- and 5-pin XLR |
| Net weight | 13.7kg |
| Gross weight | 16.3 kg |
| Packing dimensions | 535 × 435 × 500 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against WP-2. Full datasheets are one click away.
| Specification |  WP-2This model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the WP-2 does on your stage
Jet design
Jet design, produce lots of bubbles filled with fog.
Heating system
Well-designed heating system releases the fog evenly and purely, no fluid dropping off.
Fan system
Powerful fan makes the bubble fog fly higher, further.
Fluid system
Bubble and fog fluid storage in separately.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
WP-2 — quick answers
What voltage does the WP-2 require?
The 650 W Bubble Fog Machine accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the WP-2 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the WP-2?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
