MODEL WP-1M
550 W Bubble Fog Machine
A 550 W Bubble Fog Machine with 2,200 cuft/min output, 3 m throw, 3 m output height.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeBreaker
- Breaker3 A, 250 V
- Total power consumption550 W
- Heat-up timeApprox. 2 min
- Fog fluid tank capacity1.3 L
- Bubble fluid tank capacity1.3 L
- Adjustable outputNo
- Gear mode switchOFF/Bubble/Fog/Bubble fog/Remote control
- Max output volumeApprox. 2,200 cuft/min
- Max output heightApprox. 3 m
- Max output distanceApprox. 3 m
- Fog fluid consumptionApprox.125 min/L
- Bubble fluid consumptionApprox.112 min/L
- HorizontalYes
- InclinedNo
- SidelongNo
- Hang Upside DownNo
- Rigging & TrussingNo
- Wireless control√(Manual gear control )
- Wired controlW-2 wireless remote
- Control protocolNo
- DMX channelsNo
- Data ConnectorsNo
- ConsumablePRO-PW and PRO-C or PRO-J
- Net weight7.8 kg
- Gross weight8.4 kg
- Machine dimensions239.6 × 280 × 374.4 mm
- Packing dimensions295 × 340 × 430 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
WP-1M datasheet
| Model | WP-1M |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Breaker |
| Breaker | 3 A, 250 V |
| Total power consumption | 550 W |
| Heat-up time | Approx. 2 min |
| Fog fluid tank capacity | 1.3 L |
| Bubble fluid tank capacity | 1.3 L |
| Adjustable output | No |
| Gear mode switch | OFF/Bubble/Fog/Bubble fog/Remote control |
| Max output volume | Approx. 2,200 cuft/min |
| Max output height | Approx. 3 m |
| Max output distance | Approx. 3 m |
| Fog fluid consumption | Approx.125 min/L |
| Bubble fluid consumption | Approx.112 min/L |
| Horizontal | Yes |
| Inclined | No |
| Sidelong | No |
| Hang Upside Down | No |
| Rigging & Trussing | No |
| Consumable | PRO-PW and PRO-C or PRO-J |
| Machine dimensions | 239.6 × 280 × 374.4 mm |
| Wireless control | √(Manual gear control ) |
| Wired control | W-2 wireless remote |
| Control protocol | No |
| DMX channels | No |
| Data Connectors | No |
| Net weight | 7.8 kg |
| Gross weight | 8.4 kg |
| Packing dimensions | 295 × 340 × 430 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against WP-1M. Full datasheets are one click away.
| Specification |  WP-1MThis model | H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | No | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
Features
What the WP-1M does on your stage
Jet design
Jet design, produce lots of bubbles filled with fog.
Heating system
Well-designed heating system releases the fog evenly and purely, no fluid dropping off.
There are 3 modes
There are 3 modes, bubble mode, fog mode, bubble fog mode.
Fluid system
Bubble and fog fluid storage in separately.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
WP-1M — quick answers
What voltage does the WP-1M require?
The 550 W Bubble Fog Machine accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the WP-1M with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the WP-1M?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
