MODEL V-6
1,150 W Spark Spin
A 1,150 W Spark Spin with 5 m output height, DMX512 2 or 4-channel control, 20.3 kg net weight.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeBreaker
- Breaker8 A, 250 V
- Total power consumption1,150 W
- Power Input ConnectorLockable PowerCon
- Power Output ConnectorLockable PowerCon
- Heat-up timeApprox. 3 min
- Powder Tank Capacity200 g × 2
- Max output heightApprox. 5 m
- Max continuous outputApprox. 30 s
- Powder ConsumptionApprox.8 g/min × 2
- Power CordYes
- Wireless Controller ModelNo
- Wired Controller ModelNo
- On-device controlLCD control board
- Wireless controlNo
- Wired controlNo
- Control protocolDMX-512
- DMX channels2 or 4
- Data Connectors3-pin and 5-pin XLR
- Rfid CardYes
- CeYes
- RoHSYes
- Net weight20.3 kg
- Gross weight23.3 kg
- Machine dimensions352.3 × 324.5 × 382.9 mm
- Packing dimensions412 × 402 × 408 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
V-6 datasheet
| Model | V-6 |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Breaker |
| Breaker | 8 A, 250 V |
| Total power consumption | 1,150 W |
| Heat-up time | Approx. 3 min |
| Powder Tank Capacity | 200 g × 2 |
| Max output height | Approx. 5 m |
| Max continuous output | Approx. 30 s |
| Powder Consumption | Approx.8 g/min × 2 |
| Power Cord | Yes |
| Rfid Card | Yes |
| Ce | Yes |
| RoHS | Yes |
| Machine dimensions | 352.3 × 324.5 × 382.9 mm |
| Power Input Connector | Lockable PowerCon |
| Power Output Connector | Lockable PowerCon |
| Wireless Controller Model | No |
| Wired Controller Model | No |
| On-device control | LCD control board |
| Wireless control | No |
| Wired control | No |
| Control protocol | DMX-512 |
| DMX channels | 2 or 4 |
| Data Connectors | 3-pin and 5-pin XLR |
| Net weight | 20.3 kg |
| Gross weight | 23.3 kg |
| Packing dimensions | 412 × 402 × 408 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against V-6. Full datasheets are one click away.
| Specification |  V-6This model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the V-6 does on your stage
Dual head rotation, free
Dual head rotation, free direction change.
Adjustable rotation direction, rotation
Adjustable rotation direction, rotation speed, spray height.
Output performance
20° angle between the two nozzles make the spray effect is intertwined and interesting.
Can design and program
Can design and program a variety of spark effects.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
V-6 — quick answers
What voltage does the V-6 require?
The 1,150 W Spark Spin accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the V-6 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the V-6?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
