Product demo
MODEL V-4
Super Spark Machine
A Super Spark Machine with 1,500 W power, Approx.10 m output height, DMX512 3-channel control.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeBreaker
- Breaker10 A, 250 V
- Total power consumption1,500 W
- Operating Current10
- Power Input ConnectorLockable PowerCon
- Power Output ConnectorLockable PowerCon
- Heat-up timeApprox. 4.5 min
- Output AdjustableYes
- Adjustment RangeLevel 1-10
- IP ratingIPX3
- Powder Tank Capacity700 g
- Adjustable outputYes
- Volume Adjustment Level/RangeLevel 1-10
- Max output heightApprox.10 m
- Powder Consumption @ full volumeApprox. 66 g/min
- Maximum Continuous Duration @ full volumeApprox. 30 sec
- Continuous OutputNo
- Max continuous output levelLevel 10
- On-device controlLCD control board
- Wireless controlNo
- Wired controlNo
- Control protocolDMX-512
- DMX channels3
- Data Connectors3-pin and 5-pin XLR
- Rfid CardYes
- Power CordYes
- Wireless Controller ModelNo
- Net weight27 kg
- Gross weight28.8 kg
- Machine dimensions465 × 359 × 306 mm
- Packing dimensions545 × 460 × 380 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
V-4 datasheet
| Model | V-4 |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Breaker |
| Breaker | 10 A, 250 V |
| Total power consumption | 1,500 W |
| Heat-up time | Approx. 4.5 min |
| Output Adjustable | Yes |
| Adjustment Range | Level 1-10 |
| Powder Tank Capacity | 700 g |
| Adjustable output | Yes |
| Volume Adjustment Level/Range | Level 1-10 |
| Max output height | Approx.10 m |
| Powder Consumption @ full volume | Approx. 66 g/min |
| Maximum Continuous Duration @ full volume | Approx. 30 sec |
| Continuous Output | No |
| Max continuous output level | Level 10 |
| Rfid Card | Yes |
| Power Cord | Yes |
| Machine dimensions | 465 × 359 × 306 mm |
| Power Input Connector | Lockable PowerCon |
| Power Output Connector | Lockable PowerCon |
| On-device control | LCD control board |
| Wireless control | No |
| Wired control | No |
| Control protocol | DMX-512 |
| DMX channels | 3 |
| Data Connectors | 3-pin and 5-pin XLR |
| Wireless Controller Model | No |
| Operating Current | 10 |
| IP rating | IPX3 |
| Net weight | 27 kg |
| Gross weight | 28.8 kg |
| Packing dimensions | 545 × 460 × 380 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against V-4. Full datasheets are one click away.
| Specification |  V-4This model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the V-4 does on your stage
Safety protection
Stainless steel panel structure, safety and durable.
Water proof design, allows
Water proof design, allows shows not interrupted by rain(can't immerse in water).
Spark effect height can
The spark effect height can be adjusted to 10 meters.
Super big powder tank
Super big powder tank capacity.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
V-4 — quick answers
What voltage does the V-4 require?
The Super Spark Machine accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the V-4 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the V-4?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
