MODEL V-3
600 W Spark Machine
A 600 W Spark Machine with 5 m output height, DMX512 2-channel control, 7.5 kg net weight.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeFUSE
- BreakerF 5 A, 250 V
- Total power consumption600 W
- Operating Current2.6
- Power Input ConnectorLockable PowerCon
- Power Output ConnectorLockable PowerCon
- Heat-up timeApprox. 5 min
- TypeDC Axial Fan
- Quantity2 pc
- Powder Tank Capacity200 g
- Adjustable outputYes
- Volume Adjustment Level/RangeLevel 1-10
- Max output heightApprox. 5 m
- Powder Consumption @ full volumeApprox. 11.0 g/min
- Maximum Continuous Duration @ full volumeApprox. 30 sec
- Continuous OutputNo
- Max continuous output levelLevel 10
- Fully-loaded Cumulative Output Duration @ full volumeApprox. 14 min
- On-device controlLCD control board
- Wireless controlW-7/ RF 433MHz / External receiver
- Wired controlNo
- Control protocolDMX-512
- DMX channels2
- Data Connectors3-pin XLR
- Rfid CardNo
- Power CordYes
- Wireless Controller ModelW-7 / RF 315MHz / Transmitter & Receiver
- Net weight7.5 kg
- Gross weight8 kg
- Machine dimensions191× 210 × 270.8 mm
- Packing dimensions270 × 245 × 320 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
V-3 datasheet
| Model | V-3 |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | FUSE |
| Breaker | F 5 A, 250 V |
| Total power consumption | 600 W |
| Heat-up time | Approx. 5 min |
| Type | DC Axial Fan |
| Quantity | 2 pc |
| Powder Tank Capacity | 200 g |
| Adjustable output | Yes |
| Volume Adjustment Level/Range | Level 1-10 |
| Max output height | Approx. 5 m |
| Powder Consumption @ full volume | Approx. 11.0 g/min |
| Maximum Continuous Duration @ full volume | Approx. 30 sec |
| Continuous Output | No |
| Max continuous output level | Level 10 |
| Fully-loaded Cumulative Output Duration @ full volume | Approx. 14 min |
| Rfid Card | No |
| Power Cord | Yes |
| Machine dimensions | 191× 210 × 270.8 mm |
| Power Input Connector | Lockable PowerCon |
| Power Output Connector | Lockable PowerCon |
| On-device control | LCD control board |
| Wireless control | W-7/ RF 433MHz / External receiver |
| Wired control | No |
| Control protocol | DMX-512 |
| DMX channels | 2 |
| Data Connectors | 3-pin XLR |
| Wireless Controller Model | W-7 / RF 315MHz / Transmitter & Receiver |
| Operating Current | 2.6 |
| Net weight | 7.5 kg |
| Gross weight | 8 kg |
| Packing dimensions | 270 × 245 × 320 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against V-3. Full datasheets are one click away.
| Specification |  V-3This model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | DC Axial Fan | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the V-3 does on your stage
Unique design: the storage
Unique design: the storage bin flip cover warning function makes the machine safer to use.
Compact size, with belt
Compact size, with belt drive, less noise.
Higher and denser spark
Higher and denser spark, quicker eruption speed, amazing effect.
Physical Thermostat: ×
Physical Thermostat: ×.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
V-3 — quick answers
What voltage does the V-3 require?
The 600 W Spark Machine accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the V-3 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the V-3?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
