MODEL V-1
700 W Spark Machine
A 700 W Spark Machine with 4~5 m output height, DMX512 2-channel control, 10 kg net weight.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeBreaker
- Breaker5 A, 250 V
- Total power consumption700 W
- Operating Current3.0
- Power Input ConnectorLockable PowerCon
- Power Output ConnectorLockable PowerCon
- Heat-up time<3 min
- TypeBlower
- Quantity1 pc
- Current0.20
- Power Consumption of Each Unit200 W
- Output AdjustableYes
- Adjustment RangeLevel 1-10
- Powder Tank Capacity200 g
- Adjustable outputYes
- Volume Adjustment Level/RangeLevel 1-10
- Max output heightApprox. 4~5 m
- Powder Consumption @ full volumeApprox. 14.0 g/min
- Maximum Continuous Duration @ full volumeApprox. 30 sec
- Continuous OutputNo
- Max continuous output levelLevel 10
- Fully-loaded Cumulative Output Duration @ full volumeApprox. 14 min
- On-device controlLCD control board
- Wireless controlNo
- Wired controlNo
- Control protocolDMX-512
- DMX channels2
- Data Connectors3-pin and 5-pin XLR
- Rfid CardYes
- Power CordYes
- Wireless Controller ModelNo
- Net weight10 kg
- Gross weight11.4 kg
- Machine dimensions205.7 × 250.2 × 323 mm
- Packing dimensions290 × 335 × 415 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
V-1 datasheet
| Model | V-1 |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Breaker |
| Breaker | 5 A, 250 V |
| Total power consumption | 700 W |
| Heat-up time | <3 min |
| Type | Blower |
| Quantity | 1 pc |
| Current | 0.20 |
| Power Consumption of Each Unit | 200 W |
| Output Adjustable | Yes |
| Adjustment Range | Level 1-10 |
| Powder Tank Capacity | 200 g |
| Adjustable output | Yes |
| Volume Adjustment Level/Range | Level 1-10 |
| Max output height | Approx. 4~5 m |
| Powder Consumption @ full volume | Approx. 14.0 g/min |
| Maximum Continuous Duration @ full volume | Approx. 30 sec |
| Continuous Output | No |
| Max continuous output level | Level 10 |
| Fully-loaded Cumulative Output Duration @ full volume | Approx. 14 min |
| Rfid Card | Yes |
| Power Cord | Yes |
| Machine dimensions | 205.7 × 250.2 × 323 mm |
| Power Input Connector | Lockable PowerCon |
| Power Output Connector | Lockable PowerCon |
| On-device control | LCD control board |
| Wireless control | No |
| Wired control | No |
| Control protocol | DMX-512 |
| DMX channels | 2 |
| Data Connectors | 3-pin and 5-pin XLR |
| Wireless Controller Model | No |
| Operating Current | 3.0 |
| Net weight | 10 kg |
| Gross weight | 11.4 kg |
| Packing dimensions | 290 × 335 × 415 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against V-1. Full datasheets are one click away.
| Specification |  V-1This model | H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | Blower | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
Features
What the V-1 does on your stage
Safety protection
Safety, without gunpowder; Much safer than using traditional pyrotechnics.
No hazardous materials; Can
No hazardous materials; Can be used indoor.
Environmental friendly, no smoke
Environmental friendly, no smoke and odor.
Intelligent and digitalized; Recyclable
Intelligent and digitalized; Recyclable with low consumption.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
V-1 — quick answers
What voltage does the V-1 require?
The 700 W Spark Machine accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the V-1 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the V-1?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
