MODEL R-5
Two-output Electric Confetti Launcher
A Two-output Electric Confetti Launcher with 60 W power, (45°) 10 m (80 cm cannon); 5 m (40 cm cannon) throw, (90°) 10 m (80 cm cannon); 5 m (40 cm cannon) output height.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeFuse (F)
- Breaker2 A, 250 V
- Total power consumption60 W
- Operating Current0.3
- Power Input ConnectorIEC
- Max output height(90°) Approx. 10 m (80 cm cannon); Approx. 5 m (40 cm cannon)
- Max output distance(45°) Approx. 10 m (80 cm cannon); Approx. 5 m (40 cm cannon)
- On-device controlLCD control board
- Wireless controlW-6 / RF 315MHz / Built-in
- Control protocolDMX-512
- DMX channels3
- Data Connectors3- and 5-pin XLR
- Power CordYes
- Wireless Controller ModelW-6 / RF 433MHz / Transmitter
- ConsumableElectric Cannon
- Net weight5.5 kg
- Gross weight6.5 kg
- Machine dimensions315 × 205 × 211 mm
- Packing dimensions360 × 300 × 265 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
R-5 datasheet
| Model | R-5 |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Fuse (F) |
| Breaker | 2 A, 250 V |
| Total power consumption | 60 W |
| Max output height | (90°) Approx. 10 m (80 cm cannon); Approx. 5 m (40 cm cannon) |
| Max output distance | (45°) Approx. 10 m (80 cm cannon); Approx. 5 m (40 cm cannon) |
| Power Cord | Yes |
| Consumable | Electric Cannon |
| Machine dimensions | 315 × 205 × 211 mm |
| Power Input Connector | IEC |
| On-device control | LCD control board |
| Wireless control | W-6 / RF 315MHz / Built-in |
| Control protocol | DMX-512 |
| DMX channels | 3 |
| Data Connectors | 3- and 5-pin XLR |
| Wireless Controller Model | W-6 / RF 433MHz / Transmitter |
| Operating Current | 0.3 |
| Net weight | 5.5 kg |
| Gross weight | 6.5 kg |
| Packing dimensions | 360 × 300 × 265 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against R-5. Full datasheets are one click away.
| Specification |  R-5This model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the R-5 does on your stage
Compact design
Compact design.
Easy rigging
Easy floor mounting or hanging on truss.
Various color confetti cannons
Various color confetti cannons for option, plug and play, safe and convenient.
Output performance
Long output distance: 5m for 40cm confetti cannon and 10m for 80cm confetti cannon.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
R-5 — quick answers
What voltage does the R-5 require?
The Two-output Electric Confetti Launcher accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the R-5 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the R-5?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
