Product demo
MODEL PT-1500
1,350 W Fog Machine
A 1,350 W Fog Machine with 24,000 cuft/min output, 6 m throw, 2.5 L tank.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeFuse (F)
- Breaker7 A, 250 V
- Total power consumption1,350 W
- Operating Current5.9
- Power Input ConnectorHard-wired
- Heat-up timeApprox. 4.0 min
- Heater TypeAluminum Heater Block
- Fluid tank capacity2.5 L
- Adjustable outputNo
- Max output volumeApprox. 24,000 cuft/min
- Max Output DurationApprox.15 s
- Max output distanceApprox. 6 m
- Fluid Consumption @ full volumeApprox. 8.3 min/L
- Fully-loaded Cumulative Output Duration @ full volumeApprox. 20 min
- On-device controlN/A
- Wireless controlW-2 / RF 433MHz / External receiver
- Wired controlM-1
- Control protocolNo
- Power CordYes
- Wireless Controller ModelW-2 / RF 315MHz / Transmitter & Receiver
- Wired Controller ModelM-1
- ConsumableDJV-001 or D-01 or D-03 Fog Fluid
- Net weight6.8 kg
- Gross weight7.5 kg
- Machine dimensions420 × 314 × 201 mm
- Packing dimensions475 × 325 × 260 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
PT-1500 datasheet
| Model | PT-1500 |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Fuse (F) |
| Breaker | 7 A, 250 V |
| Total power consumption | 1,350 W |
| Heat-up time | Approx. 4.0 min |
| Heater Type | Aluminum Heater Block |
| Fluid tank capacity | 2.5 L |
| Adjustable output | No |
| Max output volume | Approx. 24,000 cuft/min |
| Max Output Duration | Approx.15 s |
| Max output distance | Approx. 6 m |
| Fluid Consumption @ full volume | Approx. 8.3 min/L |
| Fully-loaded Cumulative Output Duration @ full volume | Approx. 20 min |
| Power Cord | Yes |
| Consumable | DJV-001 or D-01 or D-03 Fog Fluid |
| Machine dimensions | 420 × 314 × 201 mm |
| Power Input Connector | Hard-wired |
| On-device control | N/A |
| Wireless control | W-2 / RF 433MHz / External receiver |
| Wired control | M-1 |
| Control protocol | No |
| Wireless Controller Model | W-2 / RF 315MHz / Transmitter & Receiver |
| Wired Controller Model | M-1 |
| Operating Current | 5.9 |
| Net weight | 6.8 kg |
| Gross weight | 7.5 kg |
| Packing dimensions | 475 × 325 × 260 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against PT-1500. Full datasheets are one click away.
| Specification |  PT-1500This model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | No | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the PT-1500 does on your stage
Durable and easy to operate
Durable and easy to operate.
Output performance
Safe manual controller: the output port is weak current instead of 220V.
Control
Microcomputer electronic temperature control system, instead of cheap and dangerous mechanical temperature controller.
Remote control
Wired control and wireless control.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
PT-1500 — quick answers
What voltage does the PT-1500 require?
The 1,350 W Fog Machine accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the PT-1500 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the PT-1500?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
