MODEL P-1000Y
60 W Bubble Machine
A 60 W Bubble Machine with 8 m throw, 4 m output height, DMX512 1-channel control.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeFuse (F)
- Breaker0.5 A, 250 V
- Total power consumption60 W
- Operating Current0.3
- Power Input ConnectorIEC
- Fluid tank capacity2.5 L
- Adjustable outputYes
- Max output heightApprox. 4 m
- Max output distanceApprox. 8 m
- Fluid Consumption @ full volumeApprox. 100 min/L
- Fully-loaded Cumulative Output Duration @ full volumeApprox. 250 min
- On-device controlKnob(s)
- Wireless controlW-2 / RF 315MHz / External receiver
- Control protocolDMX-512
- DMX channels1
- Data Connectors3-pin XLR
- Moving CartYes
- Power CordYes
- Wireless Controller ModelW-2 / RF 433MHz / Transmitter & Receiver
- ConsumableD-02 Bubble Fluid
- Net weight11.2 kg
- Gross weight12.3 kg
- Machine dimensions435 × 384 × 403 mm
- Packing dimensions475 × 460 × 495 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
P-1000Y datasheet
| Model | P-1000Y |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Fuse (F) |
| Breaker | 0.5 A, 250 V |
| Total power consumption | 60 W |
| Fluid tank capacity | 2.5 L |
| Adjustable output | Yes |
| Max output height | Approx. 4 m |
| Max output distance | Approx. 8 m |
| Fluid Consumption @ full volume | Approx. 100 min/L |
| Fully-loaded Cumulative Output Duration @ full volume | Approx. 250 min |
| Moving Cart | Yes |
| Power Cord | Yes |
| Consumable | D-02 Bubble Fluid |
| Machine dimensions | 435 × 384 × 403 mm |
| Power Input Connector | IEC |
| On-device control | Knob(s) |
| Wireless control | W-2 / RF 315MHz / External receiver |
| Control protocol | DMX-512 |
| DMX channels | 1 |
| Data Connectors | 3-pin XLR |
| Wireless Controller Model | W-2 / RF 433MHz / Transmitter & Receiver |
| Operating Current | 0.3 |
| Net weight | 11.2 kg |
| Gross weight | 12.3 kg |
| Packing dimensions | 475 × 460 × 495 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against P-1000Y. Full datasheets are one click away.
| Specification |  P-1000YThis model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the P-1000Y does on your stage
Fluid system
Belt drive prevents motor from fluid damage.
Output performance
Dual bubble wands, enormous bubble output.
Fan system
Adjustable fan speed.
Fluid system
Plastic fluid tank prevents corrosion and leaking.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
P-1000Y — quick answers
What voltage does the P-1000Y require?
The 60 W Bubble Machine accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the P-1000Y with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the P-1000Y?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
