Product demo
MODEL HW-IP4
Smobble 4
A Smobble 4 with 1,600 W power, 6,000 cuft/min output, 10 m throw.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeBreaker
- Breaker10A, 250 V
- Total power consumption1,600 W
- Heat-up timeApprox. 3.5 min
- Adjustable outputYes
- Max output volumeApprox. 6,000 cuft/min
- Max output heightApprox. 10 m
- Max output distanceApprox. 10 m
- Fog fluid consumptionApprox. 90.9 min/L
- Bubble fluid consumptionApprox. 12.5 min/L
- IP ratingIP54
- Bubble fluid tank capacity9L
- Haze Fluid Tank Capacity5L
- On-device Manual Control ColorScreen LCD Control Panel
- Wireless controlNo
- Wired controlNo
- Control protocolDMX512
- DMX channels4
- ConsumablePRO-PW & PRO-C or PRO-J
- Net weight34.5 kg
- Gross weight39.5kg
- Machine dimensions540 × 490 × 598mm
- Packing dimensions642 × 594 × 690mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
HW-IP4 datasheet
| Model | HW-IP4 |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Breaker |
| Breaker | 10A, 250 V |
| Total power consumption | 1,600 W |
| Heat-up time | Approx. 3.5 min |
| Adjustable output | Yes |
| Max output volume | Approx. 6,000 cuft/min |
| Max output height | Approx. 10 m |
| Max output distance | Approx. 10 m |
| Fog fluid consumption | Approx. 90.9 min/L |
| Bubble fluid consumption | Approx. 12.5 min/L |
| Bubble fluid tank capacity | 9L |
| Haze Fluid Tank Capacity | 5L |
| Consumable | PRO-PW & PRO-C or PRO-J |
| Machine dimensions | 540 × 490 × 598mm |
| On-device Manual Control Color | Screen LCD Control Panel |
| Wireless control | No |
| Wired control | No |
| Control protocol | DMX512 |
| DMX channels | 4 |
| IP rating | IP54 |
| Net weight | 34.5 kg |
| Gross weight | 39.5kg |
| Packing dimensions | 642 × 594 × 690mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against HW-IP4. Full datasheets are one click away.
| Specification |  HW-IP4This model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the HW-IP4 does on your stage
Rugged housing
High-strength integrated composite material housing, water-conducting structure design; waterproof grade IP54, suitable for outdoor use.
Jet design
Innovative Jet design, create denser and beautiful fog bubbles, greatly reducing the formation of excess smoke.
Heating system
Well-designed heating system releases the fog evenly and purely, no fluid dropping off.
Fan system
Three fans with adjustable angles make the fog bubble fly higher and further.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
HW-IP4 — quick answers
What voltage does the HW-IP4 require?
The Smobble 4 accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the HW-IP4 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the HW-IP4?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
