Product demo
MODEL HF-210S
Flame Machine
A Flame Machine with 6,00 W power, Approx.8 m-10 m (no wind) output height, DMX512 6-channel control.
- Input voltage100–240 V, 50/60 Hz
- Breaker typeBreaker
- Breaker5 A, 250 V
- Total power consumption6,00 W
- Power Input ConnectorLockable PowerCon
- Fluid tank capacity10 L
- Adjustable Output AngleYes
- Max output heightApprox.8 m-10 m (no wind)
- Effect anglesGround mode: 180°(±90°); suspended (5 meters and above) mode: 210° (±105°)
- Fluid Consumption RateApprox. 0.48 min/L
- ConsumableIsopropyl alcohol, Bio-Ethanol, Isopar-G
- On-device controlLCD control board
- Wireless controlNo
- Wired controlYes
- Control protocolDMX-512
- DMX channels6
- Data Connectors3- and 5-pin XLR
- Power CordYes
- Wireless Controller ModelNo
- Net weight36 kg
- Gross weight48.4 kg
- Machine dimensions587.6 × 362.4 × 371 mm
- Flight case Dimensions645 × 405 × 504 mm
- Packing dimensions720 × 480 × 570 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
HF-210S datasheet
| Model | HF-210S |
| Input voltage | 100–240 V, 50/60 Hz |
| Breaker type | Breaker |
| Breaker | 5 A, 250 V |
| Total power consumption | 6,00 W |
| Fluid tank capacity | 10 L |
| Adjustable Output Angle | Yes |
| Max output height | Approx.8 m-10 m (no wind) |
| Effect angles | Ground mode: 180°(±90°); suspended (5 meters and above) mode: 210° (±105°) |
| Fluid Consumption Rate | Approx. 0.48 min/L |
| Consumable | Isopropyl alcohol, Bio-Ethanol, Isopar-G |
| Power Cord | Yes |
| Machine dimensions | 587.6 × 362.4 × 371 mm |
| Flight case Dimensions | 645 × 405 × 504 mm |
| Power Input Connector | Lockable PowerCon |
| On-device control | LCD control board |
| Wireless control | No |
| Wired control | Yes |
| Control protocol | DMX-512 |
| DMX channels | 6 |
| Data Connectors | 3- and 5-pin XLR |
| Wireless Controller Model | No |
| Net weight | 36 kg |
| Gross weight | 48.4 kg |
| Packing dimensions | 720 × 480 × 570 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against HF-210S. Full datasheets are one click away.
| Specification |  HF-210SThis model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 100–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the HF-210S does on your stage
Dual ignition ensures successful
Dual ignition ensures successful ignition.
Rainproof structure design, IPX3
Rainproof structure design, IPX3 waterproof grade.
Dual valve and pump
The dual valve and dual pump design, safer and more stable.
Rotation range
The maximum rotation angle is optional: ground mode: 180° (±90°) or suspended (5 meters and above) mode: 210° (±105°).
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
HF-210S — quick answers
What voltage does the HF-210S require?
The Flame Machine accepts 100–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the HF-210S with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the HF-210S?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
