Product demo
MODEL H-S6
850 W Snow Machine
A 850 W Snow Machine with DMX512 2-channel control, 20 L. tank, 37 kg net weight.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeBreaker
- Breaker10 A, 250 V
- Total power consumption850 W
- Power Input ConnectorLockable PowerCon
- Fluid tank capacity20 L.
- Max HeightApprox. 8 m
- Max DistanceApprox. 8 m
- Noise≥ 10 m,60 dB
- Output CoverageApprox. 30 ㎡ (placed on the floor in 45°) Approx. 40 ㎡ (hung 5m height in 45°) Approx. 50 ㎡ (hung 10m height in 45°)
- Fluid Consumption @ full volumeApprox. 2.5 min/L
- On-device controlLCD control board
- Wireless controlW-7
- Wired controlK-2 (extra charge)
- Control protocolDMX-512
- DMX channels2
- Data Connectors3-pin and 5-pin XLR
- Power CordYes
- Wireless Controller ModelW-7
- Wired Controller ModelK-2
- ConsumablePRO-X or PRO-X.2 or PRO-X.3 or PRO-X.4
- Net weight37 kg
- Gross weight41 kg
- Machine dimensions593 × 552 × 622 mm
- Packing dimensions655 × 610 × 665 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
H-S6 datasheet
| Model | H-S6 |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Breaker |
| Breaker | 10 A, 250 V |
| Total power consumption | 850 W |
| Fluid tank capacity | 20 L. |
| Max Height | Approx. 8 m |
| Max Distance | Approx. 8 m |
| Noise | ≥ 10 m,60 dB |
| Output Coverage | Approx. 30 ㎡ (placed on the floor in 45°) Approx. 40 ㎡ (hung 5m height in 45°) Approx. 50 ㎡ (hung 10m height in 45°) |
| Fluid Consumption @ full volume | Approx. 2.5 min/L |
| Power Cord | Yes |
| Consumable | PRO-X or PRO-X.2 or PRO-X.3 or PRO-X.4 |
| Machine dimensions | 593 × 552 × 622 mm |
| Power Input Connector | Lockable PowerCon |
| On-device control | LCD control board |
| Wireless control | W-7 |
| Wired control | K-2 (extra charge) |
| Control protocol | DMX-512 |
| DMX channels | 2 |
| Data Connectors | 3-pin and 5-pin XLR |
| Wireless Controller Model | W-7 |
| Wired Controller Model | K-2 |
| Net weight | 37 kg |
| Gross weight | 41 kg |
| Packing dimensions | 655 × 610 × 665 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against H-S6. Full datasheets are one click away.
| Specification |  H-S6This model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the H-S6 does on your stage
LED lighting
All the accessories can be put in one flight case, convenient for transportation.
10M hose can be hung
A 10M hose can be hung on higher point or used at a distance. (An optional 20M hose to satisfy different using occasions, extra payment will be required).
Fluid system
20 L big capacity tank, avoid adding consumables frequently.
Fan system
With high-power fan, adjustable snow output, to meet any large realistic snow.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
H-S6 — quick answers
What voltage does the H-S6 require?
The 850 W Snow Machine accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the H-S6 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the H-S6?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
