Product demo
MODEL H-IP4000
Skymist Hazer
A Skymist Hazer with 2,500 W power, 55,000 cuft/min output, DMX512 3-channel control.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeBreaker
- Breaker15 A, 250 V
- Total power consumption2,500 W
- Power Input ConnectorLockable PowerCon
- Heat-up timeApprox. 8 min
- Fluid tank capacity10 L
- Max output volumeApprox. 55,000 cuft/min
- Fluid Consumption Rate of Haze Mode 100% outputApprox. 25 min/L
- Fluid Consumption Rate of Fog Mode 100% outputApprox. 5 min/L
- Max CoverageApprox. 600 ㎡
- IP ratingIP54
- Wireless controlNo
- Wired controlNo
- Control protocolDMX-512 or RDM
- DMX channels3
- Data Connectors3-pin and 5-pin XLR
- Flight CaseYes
- Power CordYes
- Wireless Controller ModelNo
- Wired Controller ModelNo
- ConsumablePRO-C or PRO-A Haze Fluid
- Net weight47.5 kg
- With Flight Case Weigh61.5 kg
- Gross weight64 kg
- Machine dimensions583 × 545 × 796 mm
- Flight Case Dimensions595 × 556 × 834 mm
- Packing dimensions618 × 580 × 755 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
H-IP4000 datasheet
| Model | H-IP4000 |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Breaker |
| Breaker | 15 A, 250 V |
| Total power consumption | 2,500 W |
| Heat-up time | Approx. 8 min |
| Fluid tank capacity | 10 L |
| Max output volume | Approx. 55,000 cuft/min |
| Fluid Consumption Rate of Haze Mode 100% output | Approx. 25 min/L |
| Fluid Consumption Rate of Fog Mode 100% output | Approx. 5 min/L |
| Max Coverage | Approx. 600 ㎡ |
| Flight Case | Yes |
| Power Cord | Yes |
| Consumable | PRO-C or PRO-A Haze Fluid |
| With Flight Case Weigh | 61.5 kg |
| Machine dimensions | 583 × 545 × 796 mm |
| Flight Case Dimensions | 595 × 556 × 834 mm |
| Power Input Connector | Lockable PowerCon |
| Wireless control | No |
| Wired control | No |
| Control protocol | DMX-512 or RDM |
| DMX channels | 3 |
| Data Connectors | 3-pin and 5-pin XLR |
| Wireless Controller Model | No |
| Wired Controller Model | No |
| IP rating | IP54 |
| Net weight | 47.5 kg |
| Gross weight | 64 kg |
| Packing dimensions | 618 × 580 × 755 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against H-IP4000. Full datasheets are one click away.
| Specification |  H-IP4000This model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 or RDM | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the H-IP4000 does on your stage
Rugged housing
Enhanced high-intensity composite housing, stainless and durable.
Rainproof structure design, IP54
Rainproof structure design, IP54 waterproof grade.
Fan system
With waterproof quiet fan, strong wind, haze output is quieter.
Output performance
Baffle angle adjustable, easy control of haze output angle.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
H-IP4000 — quick answers
What voltage does the H-IP4000 require?
The Skymist Hazer accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the H-IP4000 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the H-IP4000?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
