Product demo
MODEL H-9
Pro DMX Fan
A Pro DMX Fan with 150 W power, DMX512 1-channel control, 11 kg net weight.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeFuse (F)
- Breaker2 A, 250 V
- Total power consumption150 W
- Operating Current0.7
- Power Input ConnectorLockable PowerCon
- Power Output ConnectorLockable PowerCon
- TypeAC Centrifugal Blower
- Quantity1 pc
- Power Consumption of Each Unit150 W
- Output AdjustableYes
- Adjustment Range1-100
- Wind Angle0°~270°
- Fan Speed0~2,500 r/min
- Adjustable outputYes
- Volume Adjustment Level/Range1–100%
- Maximum Continuous Duration @ full volumeUnlimited
- Continuous OutputYes
- Max continuous output level100%
- On-device controlLCD control board
- Wireless controlW-5 / RF 433MHz / Built-in
- Wired controlNo
- Control protocolDMX-512
- DMX channels1
- Data Connectors3-pin and 5-pin XLR
- Power CordYes
- Wireless Controller ModelW-5 / RF 433MHz / Transmitter
- Wired Controller ModelNo
- Net weight11 kg
- Gross weight14.5 kg
- Machine dimensions443 × 258.5 × 468.2 mm
- Packing dimensions533 × 453 × 418 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
H-9 datasheet
| Model | H-9 |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Fuse (F) |
| Breaker | 2 A, 250 V |
| Total power consumption | 150 W |
| Type | AC Centrifugal Blower |
| Quantity | 1 pc |
| Power Consumption of Each Unit | 150 W |
| Output Adjustable | Yes |
| Adjustment Range | 1-100 |
| Wind Angle | 0°~270° |
| Adjustable output | Yes |
| Volume Adjustment Level/Range | 1–100% |
| Maximum Continuous Duration @ full volume | Unlimited |
| Continuous Output | Yes |
| Max continuous output level | 100% |
| Power Cord | Yes |
| Machine dimensions | 443 × 258.5 × 468.2 mm |
| Fan Speed | 0~2,500 r/min |
| Power Input Connector | Lockable PowerCon |
| Power Output Connector | Lockable PowerCon |
| On-device control | LCD control board |
| Wireless control | W-5 / RF 433MHz / Built-in |
| Wired control | No |
| Control protocol | DMX-512 |
| DMX channels | 1 |
| Data Connectors | 3-pin and 5-pin XLR |
| Wireless Controller Model | W-5 / RF 433MHz / Transmitter |
| Wired Controller Model | No |
| Operating Current | 0.7 |
| Net weight | 11 kg |
| Gross weight | 14.5 kg |
| Packing dimensions | 533 × 453 × 418 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against H-9. Full datasheets are one click away.
| Specification |  H-9This model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | AC Centrifugal Blower | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the H-9 does on your stage
Rugged housing
Shell is made of sturdy metal material, firm and durable.
Output performance
With high-strength plastic blades, massive output but low noise.
Adjustable wind speed
Adjustable wind speed.
Hung or placed on the floor
Hung or placed on the floor.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
H-9 — quick answers
What voltage does the H-9 require?
The Pro DMX Fan accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the H-9 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the H-9?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
