MODEL H-8S
Pro DMX Bubble Machine
A Pro DMX Bubble Machine with 200 W power, 8 m throw, 4 m output height.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeFuse (F)
- Breaker2 A, 250 V
- Total power consumption200 W
- Operating Current0.9
- Power Input ConnectorLockable PowerCon
- Power Output ConnectorLockable PowerCon
- Fluid tank capacity3 L
- Adjustable outputYes
- Max output heightApprox. 4 m
- Max output distanceApprox. 8 m
- Fluid Consumption @ full volumeApprox. 64 min/L
- Maximum Continuous Duration @ full volumeApprox. 2 h
- Continuous OutputYes
- Max continuous output level100%
- Fully-loaded Cumulative Output Duration @ full volumeApprox. 224 min
- On-device controlLCD control board
- Wireless controlW-4 / RF 433MHz / Built-in
- Control protocolDMX-512
- DMX channels1
- Data Connectors3- and 5-pin XLR
- Power CordYes
- Wireless Controller ModelW-4 / RF 433MHz / Transmitter
- ConsumablePRO-P Bubble Fluid
- Weight & Dimensions
- Net weight17.5 kg
- Gross weight20.4 kg
- Machine dimensions380 × 271 × 427.5 mm
- Packing dimensions518 × 403 × 508 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
H-8S datasheet
| Model | H-8S |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Fuse (F) |
| Breaker | 2 A, 250 V |
| Total power consumption | 200 W |
| Fluid tank capacity | 3 L |
| Adjustable output | Yes |
| Max output height | Approx. 4 m |
| Max output distance | Approx. 8 m |
| Fluid Consumption @ full volume | Approx. 64 min/L |
| Maximum Continuous Duration @ full volume | Approx. 2 h |
| Continuous Output | Yes |
| Max continuous output level | 100% |
| Fully-loaded Cumulative Output Duration @ full volume | Approx. 224 min |
| Power Cord | Yes |
| Consumable | PRO-P Bubble Fluid |
| Machine dimensions | 380 × 271 × 427.5 mm |
| Power Input Connector | Lockable PowerCon |
| Power Output Connector | Lockable PowerCon |
| On-device control | LCD control board |
| Wireless control | W-4 / RF 433MHz / Built-in |
| Control protocol | DMX-512 |
| DMX channels | 1 |
| Data Connectors | 3- and 5-pin XLR |
| Wireless Controller Model | W-4 / RF 433MHz / Transmitter |
| Operating Current | 0.9 |
| Weight & Dimensions | |
| Net weight | 17.5 kg |
| Gross weight | 20.4 kg |
| Packing dimensions | 518 × 403 × 508 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against H-8S. Full datasheets are one click away.
| Specification |  H-8SThis model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the H-8S does on your stage
Output performance
Nozzle-pipe delivery system which protects each bubble from the disturbance of the machine parts and each other to reduce bubble failure rate.
Output performance
Dual nozzles generate enormous quantities of bubbles.
Fluid system
Enclosed fluid tank stores and keeps fluid protected against the environmental elements for long time to ensure the quality of bubble projection.
Fluid system
Enclosed fluid tank allows machine’s transportation with fluid.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
H-8S — quick answers
What voltage does the H-8S require?
The Pro DMX Bubble Machine accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the H-8S with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the H-8S?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
