MODEL H-4S
Oil-based Haze Machine
An Oil-based Haze Machine with 550 W power, 3,200 cuft/min output, 9m throw.
- Input voltage220–240 V, 50/60 Hz
- Total power consumption550 W
- Max output volumeApprox. 3,200 cuft/min
- Max Output CoverageApprox.200 m²
- Max output distanceApprox. 9m
- Fluid Consumption @ full volumeApprox. 25 h/L
- Control protocolDMX-512
- DMX channels2
- IP ratingIPX1
- Fluid tank capacity2.5 L
- ConsumablePRO-H1L Oil Base Haze Fulid
- Net weight29.5 kg
- Gross weight31.2 kg
- Machine dimensions524 × 374 × 371.5 mm
- Packing dimensions630 × 480 × 473 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
H-4S datasheet
| Model | H-4S |
| Input voltage | 220–240 V, 50/60 Hz |
| Total power consumption | 550 W |
| Max output volume | Approx. 3,200 cuft/min |
| Max Output Coverage | Approx.200 m² |
| Max output distance | Approx. 9m |
| Fluid Consumption @ full volume | Approx. 25 h/L |
| Fluid tank capacity | 2.5 L |
| Consumable | PRO-H1L Oil Base Haze Fulid |
| Machine dimensions | 524 × 374 × 371.5 mm |
| Control protocol | DMX-512 |
| DMX channels | 2 |
| IP rating | IPX1 |
| Net weight | 29.5 kg |
| Gross weight | 31.2 kg |
| Packing dimensions | 630 × 480 × 473 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against H-4S. Full datasheets are one click away.
| Specification |  H-4SThis model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the H-4S does on your stage
DMX control
Integration in a stackable flight case makes the DMX hazer tough, durable and easy to carry.
Heating system
Low-noise operation without air compressor ideal for theater and stage applications.
Produces fine, translucent haze
Produces fine, translucent haze without nebulizing the room at the same time.
LED lighting
Ideal for accentuating light and laser beams.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
H-4S — quick answers
What voltage does the H-4S require?
The Oil-based Haze Machine accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the H-4S with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the H-4S?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
