MODEL H-2VSD
Dual Output LED Super Jet
A Dual Output LED Super Jet with 3,100 W power, 78,000 cuft/min output, 12 m output height.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeBreaker
- Breaker16 A, 250 V
- Total power consumption3,100 W
- Operating Current13.5
- Power Input ConnectorLockable PowerCon
- Heat-up timeApprox. 9.0 min
- Heater TypeAluminum Heater Block
- LED colorRGBA
- LED typeQuad-Color
- Power per LED8 W
- LED quantity37 pcs
- Total Power of LED296 W
- Quantity of Inner LED7 pcs
- Total Power of Inner LED56 W
- Quantity of Outer LED30 pcs
- Total Power of Outer LED240 W
- Fluid tank capacity5 L
- Adjustable outputNo
- Max output volumeApprox. 78,000 cuft/min
- Max output heightApprox. 12 m
- Fluid Consumption @ full volumeApprox. 390.0 mL/min
- Maximum Continuous Duration @ full volumeApprox. 10 sec
- Continuous OutputNo
- Fully-loaded Cumulative Output Duration @ full volumeApprox. 8 min
- Consumable Type for Standard Output TestPRO-V
- On-device controlLCD control board
- Wireless controlNo
- Wired controlNo
- Control protocolDMX-512
- DMX channels14 or 15
- Data Connectors3-pin and 5-pin XLR
- Power CordYes
- Wireless Controller ModelNo
- ConsumablePRO-V
- Net weight29 kg
- Gross weight32.3 kg
- Machine dimensions605.8 × 321 × 323.5 mm
- Packing dimensions670 × 410 × 415 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
H-2VSD datasheet
| Model | H-2VSD |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Breaker |
| Breaker | 16 A, 250 V |
| Total power consumption | 3,100 W |
| Heat-up time | Approx. 9.0 min |
| Heater Type | Aluminum Heater Block |
| LED type | Quad-Color |
| Power per LED | 8 W |
| LED quantity | 37 pcs |
| Total Power of LED | 296 W |
| Quantity of Inner LED | 7 pcs |
| Total Power of Inner LED | 56 W |
| Quantity of Outer LED | 30 pcs |
| Total Power of Outer LED | 240 W |
| Fluid tank capacity | 5 L |
| Adjustable output | No |
| Max output volume | Approx. 78,000 cuft/min |
| Max output height | Approx. 12 m |
| Fluid Consumption @ full volume | Approx. 390.0 mL/min |
| Maximum Continuous Duration @ full volume | Approx. 10 sec |
| Continuous Output | No |
| Fully-loaded Cumulative Output Duration @ full volume | Approx. 8 min |
| Consumable Type for Standard Output Test | PRO-V |
| Power Cord | Yes |
| Consumable | PRO-V |
| Machine dimensions | 605.8 × 321 × 323.5 mm |
| LED color | RGBA |
| Power Input Connector | Lockable PowerCon |
| On-device control | LCD control board |
| Wireless control | No |
| Wired control | No |
| Control protocol | DMX-512 |
| DMX channels | 14 or 15 |
| Data Connectors | 3-pin and 5-pin XLR |
| Wireless Controller Model | No |
| Operating Current | 13.5 |
| Net weight | 29 kg |
| Gross weight | 32.3 kg |
| Packing dimensions | 670 × 410 × 415 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against H-2VSD. Full datasheets are one click away.
| Specification |  H-2VSDThis model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the H-2VSD does on your stage
Output performance
Dual output for strong plume.
Jet design
Newest global patent "Super-Jet".
Immediate-Stop and Anti-Squirting Plus
Immediate-Stop and Anti-Squirting Plus patent technology.
Jet design
Independent color changes for flame core, two amazing colors of jet.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
H-2VSD — quick answers
What voltage does the H-2VSD require?
The Dual Output LED Super Jet accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the H-2VSD with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the H-2VSD?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
