Product demo
MODEL DSK-1600VM
LED Swing Super Jet
A LED Swing Super Jet with 1,600 W power, 32,000 cuft/min output, 7–8 m output height.
- Input voltageAC 220–240 V, 50/60 Hz
- Breaker8 A, 250 V
- Total power consumption1,600 W
- Power per LED10 W × 8 pcs
- LED colorRGBAUV
- Heat-up timeApprox. 4 min
- Maximum Continuous DurationApprox. 7 s
- Max output volumeApprox. 32,000 cuft/min
- Fluid consumptionApprox. 7.5 min/L
- Max output heightApprox. 7–8 m
- Dmx-512✔
- DMX channels16
- Wireless controlW-2 updated version
- Fluid tank capacity3 L
- Net weight11 kg
- Gross weight13.3 kg
- Machine dimensions444 × 400.1 × 223.8 mm
- Packing dimensions511× 486 × 273 mm
- ConsumablePRO-V
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
DSK-1600VM datasheet
| Model | DSK-1600VM |
| Input voltage | AC 220–240 V, 50/60 Hz |
| Breaker | 8 A, 250 V |
| Total power consumption | 1,600 W |
| Power per LED | 10 W × 8 pcs |
| Heat-up time | Approx. 4 min |
| Maximum Continuous Duration | Approx. 7 s |
| Max output volume | Approx. 32,000 cuft/min |
| Fluid consumption | Approx. 7.5 min/L |
| Max output height | Approx. 7–8 m |
| Fluid tank capacity | 3 L |
| Machine dimensions | 444 × 400.1 × 223.8 mm |
| Consumable | PRO-V |
| LED color | RGBAUV |
| Dmx-512 | ✔ |
| DMX channels | 16 |
| Wireless control | W-2 updated version |
| Net weight | 11 kg |
| Gross weight | 13.3 kg |
| Packing dimensions | 511× 486 × 273 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against DSK-1600VM. Full datasheets are one click away.
| Specification |  DSK-1600VMThis model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | — | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | AC 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the DSK-1600VM does on your stage
"Immediate-stop" patented technology
"Immediate-stop" patented technology.
Advanced "Anti-Squirting Plus" technology
Advanced "Anti-Squirting Plus" technology, greatly reduced the probability of squirting water.
Output performance
With horizontal rotation angle of 90°, max output distance can reach to 7-8m.
LED lighting
8PCS 10W RGBAUV five-in-one LED lights create colorful fog effect.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
DSK-1600VM — quick answers
What voltage does the DSK-1600VM require?
The LED Swing Super Jet accepts AC 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the DSK-1600VM with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the DSK-1600VM?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
