MODEL DSK-1500V
LED Vertical Fog Machine
A LED Vertical Fog Machine with 1,500 W power, 32,000 cuft/min output, 6.0~8.0 m output height.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeFuse (F)
- Breaker8 A, 250 V
- Total power consumption1,500 W
- Operating Current6.5
- Power Input ConnectorIEC
- Heat-up timeApprox. 4.0 min
- Heater TypeAluminum Heater Block
- LED colorRGB
- LED typeSingle Color
- Power per LED3 W
- LED quantity21 pcs
- Quantity of red7 pcs
- Quantity of green7 pcs
- Quantity of blue7 pcs
- Total Power of LED63 W
- Fluid tank capacity2.5 L
- Adjustable outputNo
- Volume Adjustment Level/RangeNo
- Angle Adjustment Level/RangeNo
- Max output volumeApprox. 32,000 cuft/min
- Max output heightApprox. 6.0~8.0 m
- Fluid Consumption @ full volumeApprox. 6.3 min/L
- Maximum Continuous Duration @ full volumeApprox. 7 sec
- Continuous OutputNo
- Fully-loaded Cumulative Output Duration @ full volumeApprox. 15 min
- Consumable Type for Standard Output TestPRO-V
- On-device control7-seg digital display & Physical manual trigger
- Wireless controlW-5 /RF 433MHz /Built-in
- Wired controlNo
- Control protocolDMX-512
- DMX channels8
- Data Connectors3- and 5-pin XLR
- Power CordYes
- Wireless Controller ModelW-5 / RF 433MHz / Transmitter
- ConsumablePRO-V
- Net weight8.7 kg
- Gross weight9.9 kg
- Machine dimensions474.5 × 314 × 205.2 mm
- Packing dimensions510 × 375 × 250 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
DSK-1500V datasheet
| Model | DSK-1500V |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Fuse (F) |
| Breaker | 8 A, 250 V |
| Total power consumption | 1,500 W |
| Heat-up time | Approx. 4.0 min |
| Heater Type | Aluminum Heater Block |
| LED type | Single Color |
| Power per LED | 3 W |
| LED quantity | 21 pcs |
| Quantity of red | 7 pcs |
| Quantity of green | 7 pcs |
| Quantity of blue | 7 pcs |
| Total Power of LED | 63 W |
| Fluid tank capacity | 2.5 L |
| Adjustable output | No |
| Volume Adjustment Level/Range | No |
| Angle Adjustment Level/Range | No |
| Max output volume | Approx. 32,000 cuft/min |
| Max output height | Approx. 6.0~8.0 m |
| Fluid Consumption @ full volume | Approx. 6.3 min/L |
| Maximum Continuous Duration @ full volume | Approx. 7 sec |
| Continuous Output | No |
| Fully-loaded Cumulative Output Duration @ full volume | Approx. 15 min |
| Consumable Type for Standard Output Test | PRO-V |
| Power Cord | Yes |
| Consumable | PRO-V |
| Machine dimensions | 474.5 × 314 × 205.2 mm |
| LED color | RGB |
| Power Input Connector | IEC |
| On-device control | 7-seg digital display & Physical manual trigger |
| Wireless control | W-5 /RF 433MHz /Built-in |
| Wired control | No |
| Control protocol | DMX-512 |
| DMX channels | 8 |
| Data Connectors | 3- and 5-pin XLR |
| Wireless Controller Model | W-5 / RF 433MHz / Transmitter |
| Operating Current | 6.5 |
| Net weight | 8.7 kg |
| Gross weight | 9.9 kg |
| Packing dimensions | 510 × 375 × 250 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against DSK-1500V. Full datasheets are one click away.
| Specification |  DSK-1500VThis model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the DSK-1500V does on your stage
LED lighting
21pcs 3W RGB LEDs produces colorful fog effect.
Various placing ways, can
Various placing ways, can be placed horizontally or on its side, or hung up-side-down.
Immediate-Stop patented technology
Immediate-Stop patented technology.
Advanced "Anti-Squirting Plus" technology
Advanced "Anti-Squirting Plus" technology, greatly reduced the probability of squirting water.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
DSK-1500V — quick answers
What voltage does the DSK-1500V require?
The LED Vertical Fog Machine accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the DSK-1500V with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the DSK-1500V?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
