MODEL DJ-700
1,200 W Haze Machine
A 1,200 W Haze Machine with 4,000 cuft/min output, 3 L tank, 6 kg net weight.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeFuse (F)
- Breaker7A/250V
- Total power consumption1,200 W
- Operating Current5.2
- Power Input ConnectorIEC
- Heat-up timeApprox. 3.0 min
- Heater TypeFast Coil Heater
- Fluid tank capacity3 L
- Adjustable outputYes
- Volume Adjustment Level/Range1-100
- Angle Adjustment Level/Range1
- Max output volumeApprox. 4,000 cuft/min
- Fluid Consumption @ full volumeApprox. 196 min/L
- Maximum Continuous Duration @ full volumeUnlimited
- Continuous OutputYes
- Max continuous output level100%
- Fully-loaded Cumulative Output Duration @ full volumeApprox. 750 min
- Consumable Type for Standard Output TestPRO-C/PRO-J
- On-device control7-seg digital display & Knob(s)
- Wireless controlW-4 / RF 433MHz / Built-in
- Wired controlNo
- Control protocolDMX-512
- DMX channels2
- Data Connectors3-pin XLR
- Power CordYes
- Wireless Controller ModelW-4 / RF 433MHz / Transmitter
- Wired Controller ModelNo
- ConsumablePRO-C or PRO-J Haze Fluid
- Net weight6 kg
- Gross weight7.4 kg
- Machine dimensions396 × 200 × 277 mm
- Packing dimensions460 × 315 × 315 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
DJ-700 datasheet
| Model | DJ-700 |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Fuse (F) |
| Breaker | 7A/250V |
| Total power consumption | 1,200 W |
| Heat-up time | Approx. 3.0 min |
| Heater Type | Fast Coil Heater |
| Fluid tank capacity | 3 L |
| Adjustable output | Yes |
| Volume Adjustment Level/Range | 1-100 |
| Angle Adjustment Level/Range | 1 |
| Max output volume | Approx. 4,000 cuft/min |
| Fluid Consumption @ full volume | Approx. 196 min/L |
| Maximum Continuous Duration @ full volume | Unlimited |
| Continuous Output | Yes |
| Max continuous output level | 100% |
| Fully-loaded Cumulative Output Duration @ full volume | Approx. 750 min |
| Consumable Type for Standard Output Test | PRO-C/PRO-J |
| Power Cord | Yes |
| Consumable | PRO-C or PRO-J Haze Fluid |
| Machine dimensions | 396 × 200 × 277 mm |
| Power Input Connector | IEC |
| On-device control | 7-seg digital display & Knob(s) |
| Wireless control | W-4 / RF 433MHz / Built-in |
| Wired control | No |
| Control protocol | DMX-512 |
| DMX channels | 2 |
| Data Connectors | 3-pin XLR |
| Wireless Controller Model | W-4 / RF 433MHz / Transmitter |
| Wired Controller Model | No |
| Operating Current | 5.2 |
| Net weight | 6 kg |
| Gross weight | 7.4 kg |
| Packing dimensions | 460 × 315 × 315 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against DJ-700. Full datasheets are one click away.
| Specification |  DJ-700This model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the DJ-700 does on your stage
Even and thin haze
Even and thin haze effect.
Heating system
New and fast heater, almost free from clogging.
Safety protection
Low noise and environmental protection.
Fluid system
3 liter fluid tank-12.5 hours on full output.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
DJ-700 — quick answers
What voltage does the DJ-700 require?
The 1,200 W Haze Machine accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the DJ-700 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the DJ-700?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
