MODEL DJ-660
Oil-based Haze Machine
An Oil-based Haze Machine with 500 W power, 3,000 cuft/min output, DMX512 2-channel control.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeFuse (F)
- Breaker5 A, 250 V
- Total power consumption500 W
- Operating Current2.2
- Power Input ConnectorIEC
- Heat-up time0 min
- Fluid tank capacity2.5 L
- Max output volumeApprox. 3,000 cuft/min
- Fluid Consumption @ full volumeApprox. 10 h/L
- Maximum Continuous Duration @ full volumeUnlimited
- Continuous OutputYes
- Max continuous output level100%
- Fully-loaded Cumulative Output Duration @ full volumeApprox. 3000 min
- On-device controlLCD control board
- Wireless controlNo
- Wired controlNo
- Control protocolDMX-512
- DMX channels2
- Data Connectors3-pin XLR
- Flight CaseYes
- Power CordYes
- Wireless Controller ModelNo
- Wired Controller ModelNo
- ConsumablePRO-H1L Oil Base Haze Fulid
- Net weight28 kg
- Gross weight30.5 kg
- Machine dimensions514 × 387 × 370 mm
- Packing dimensions590 × 450 × 460 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
DJ-660 datasheet
| Model | DJ-660 |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Fuse (F) |
| Breaker | 5 A, 250 V |
| Total power consumption | 500 W |
| Heat-up time | 0 min |
| Fluid tank capacity | 2.5 L |
| Max output volume | Approx. 3,000 cuft/min |
| Fluid Consumption @ full volume | Approx. 10 h/L |
| Maximum Continuous Duration @ full volume | Unlimited |
| Continuous Output | Yes |
| Max continuous output level | 100% |
| Fully-loaded Cumulative Output Duration @ full volume | Approx. 3000 min |
| Flight Case | Yes |
| Power Cord | Yes |
| Consumable | PRO-H1L Oil Base Haze Fulid |
| Machine dimensions | 514 × 387 × 370 mm |
| Power Input Connector | IEC |
| On-device control | LCD control board |
| Wireless control | No |
| Wired control | No |
| Control protocol | DMX-512 |
| DMX channels | 2 |
| Data Connectors | 3-pin XLR |
| Wireless Controller Model | No |
| Wired Controller Model | No |
| Operating Current | 2.2 |
| Net weight | 28 kg |
| Gross weight | 30.5 kg |
| Packing dimensions | 590 × 450 × 460 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against DJ-660. Full datasheets are one click away.
| Specification |  DJ-660This model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the DJ-660 does on your stage
On-device control
User-friendly LCD display and operation.
Fan system
Angle and speed adjustable fan using DC12V to ensure operation safety.
Professional anti-leaking tank prevents
Professional anti-leaking tank prevents spill during transportation.
Quiet, Low noise and durable
Quiet, Low noise and durable.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
DJ-660 — quick answers
What voltage does the DJ-660 require?
The Oil-based Haze Machine accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the DJ-660 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the DJ-660?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
