Product demo
MODEL DJ-300
Mini Haze Machine
A Mini Haze Machine with 230 W power, 3,000 cuft/min output, DMX512 1-channel control.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeFuse (F)
- Breaker3 A, 250 V
- Total power consumption230 W
- Operating Current1.0
- Power Input ConnectorHard-wired
- Heat-up timeApprox. 2 min 30 s
- Heater TypeFast Coil Heater
- Fluid tank capacity1.5 L
- Adjustable outputYes
- Volume Adjustment Level/Range1-3
- Max output volumeApprox. 3,000 cuft/min
- Fluid Consumption @ full volumeApprox. 333 min/L
- Maximum Continuous Duration @ full volumeUnlimited
- Continuous OutputYes
- Max continuous output level100%
- Fully-loaded Cumulative Output Duration @ full volumeApprox. 499 min
- Consumable Type for Standard Output TestDJV-003
- On-device control7-seg digital display & Knob(s)
- Wireless controlOptional W-2 / RF 315MHz / External receiver
- Wired controlOptional M-1
- Control protocolDMX-512
- DMX channels1
- Data Connectors3-pin XLR
- Power CordYes
- Wireless Controller ModelOptional W-2 / RF 315MHz / Transmitter & Receiver
- Wired Controller ModelOptional M-1
- ConsumableDJV-003 Haze Fluid
- Net weight4 kg
- Gross weight4.5 kg
- Machine dimensions336 × 150 × 253 mm
- Packing dimensions355 × 255 × 275 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
DJ-300 datasheet
| Model | DJ-300 |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Fuse (F) |
| Breaker | 3 A, 250 V |
| Total power consumption | 230 W |
| Heat-up time | Approx. 2 min 30 s |
| Heater Type | Fast Coil Heater |
| Fluid tank capacity | 1.5 L |
| Adjustable output | Yes |
| Volume Adjustment Level/Range | 1-3 |
| Max output volume | Approx. 3,000 cuft/min |
| Fluid Consumption @ full volume | Approx. 333 min/L |
| Maximum Continuous Duration @ full volume | Unlimited |
| Continuous Output | Yes |
| Max continuous output level | 100% |
| Fully-loaded Cumulative Output Duration @ full volume | Approx. 499 min |
| Consumable Type for Standard Output Test | DJV-003 |
| Power Cord | Yes |
| Consumable | DJV-003 Haze Fluid |
| Machine dimensions | 336 × 150 × 253 mm |
| Power Input Connector | Hard-wired |
| On-device control | 7-seg digital display & Knob(s) |
| Wireless control | Optional W-2 / RF 315MHz / External receiver |
| Wired control | Optional M-1 |
| Control protocol | DMX-512 |
| DMX channels | 1 |
| Data Connectors | 3-pin XLR |
| Wireless Controller Model | Optional W-2 / RF 315MHz / Transmitter & Receiver |
| Wired Controller Model | Optional M-1 |
| Operating Current | 1.0 |
| Net weight | 4 kg |
| Gross weight | 4.5 kg |
| Packing dimensions | 355 × 255 × 275 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against DJ-300. Full datasheets are one click away.
| Specification |  DJ-300This model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the DJ-300 does on your stage
Even and thin haze
Even and thin haze effect.
Heating system
New and fast heater, almost free from clogging.
Safety protection
Low noise and environmental protection.
Fluid system
1.5 liter fluid tank - 8.2 hours on full output.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
DJ-300 — quick answers
What voltage does the DJ-300 require?
The Mini Haze Machine accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the DJ-300 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the DJ-300?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
