- Vortex ring launcher, 10 m reach
- RGB 3-in-1 LED colorful rings
- Show-ready in ~1 min 50 s
- DMX512 + LCD control board
MODEL DHZ-660
Oil-based Haze Machine
An Oil-based Haze Machine with 500 W power, 3,200 cuft/min output, DMX512 2-channel control.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeFuse (F)
- Breaker5 A, 250 V
- Total power consumption500 W
- Operating Current2.2
- Power Input ConnectorIEC
- Heat-up time0 min
- Fluid tank capacity2.5 L
- Max output volumeApprox. 3,200 cuft/min
- Fluid Consumption @ full volumeApprox. 25 h/L
- Maximum Continuous Duration @ full volumeUnlimited
- Continuous OutputYes
- Max continuous output level100%
- Fully-loaded Cumulative Output Duration @ full volumeApprox. 3,750 min
- On-device controlLCD control board
- Wireless controlNo
- Wired controlNo
- Control protocolDMX-512
- DMX channels2
- Data Connectors3-pin XLR
- Flight CaseYes
- Power CordYes
- Wireless Controller ModelNo
- Wired Controller ModelNo
- ConsumablePRO-H1L Oil Base Haze Fluid
- Net weight33.2 kg / 73.2 lb.
- Gross weight35.7 kg / 78.7 lb.
- Machine dimensions521 × 396 × 369 mm / 20.5 × 15.6 × 14.5
- Packing dimensions590 × 450 × 460 mm / 23.2 × 17.7 × 18.1
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
DHZ-660 datasheet
| Model | DHZ-660 |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Fuse (F) |
| Breaker | 5 A, 250 V |
| Total power consumption | 500 W |
| Heat-up time | 0 min |
| Fluid tank capacity | 2.5 L |
| Max output volume | Approx. 3,200 cuft/min |
| Fluid Consumption @ full volume | Approx. 25 h/L |
| Maximum Continuous Duration @ full volume | Unlimited |
| Continuous Output | Yes |
| Max continuous output level | 100% |
| Fully-loaded Cumulative Output Duration @ full volume | Approx. 3,750 min |
| Flight Case | Yes |
| Power Cord | Yes |
| Consumable | PRO-H1L Oil Base Haze Fluid |
| Machine dimensions | 521 × 396 × 369 mm / 20.5 × 15.6 × 14.5 |
| Power Input Connector | IEC |
| On-device control | LCD control board |
| Wireless control | No |
| Wired control | No |
| Control protocol | DMX-512 |
| DMX channels | 2 |
| Data Connectors | 3-pin XLR |
| Wireless Controller Model | No |
| Wired Controller Model | No |
| Operating Current | 2.2 |
| Net weight | 33.2 kg / 73.2 lb. |
| Gross weight | 35.7 kg / 78.7 lb. |
| Packing dimensions | 590 × 450 × 460 mm / 23.2 × 17.7 × 18.1 |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against DHZ-660. Full datasheets are one click away.
| Specification |  DHZ-660This model | H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
Features
What the DHZ-660 does on your stage
On-device control
User-friendly LCD display and operation.
Fan system
Angle and speed adjustable fan using DC 12V to ensure operation safety.
Quiet, Low noise and durable
Quiet, Low noise and durable.
Dry and fine haze
Dry and fine haze, diffuse fast.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
DHZ-660 — quick answers
What voltage does the DHZ-660 require?
The Oil-based Haze Machine accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the DHZ-660 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the DHZ-660?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
