Product demo
MODEL DH-2.4
Tcpumper
A Tcpumper with 2,500 W power, DMX512 6-channel control, 30 L tank.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeBreaker
- Breaker10 A, 250 V
- Total power consumption2,500 W
- Power Input ConnectorLockable PowerCon
- Fluid tank capacity30 L
- Pump OutputApprox. 15 L/min
- Max. Supported Flame heads4 pcs
- Working ModeFueling /Pressurize
- On-device controlLCD control board
- Wireless controlNo
- Control protocolDMX-512
- DMX channels6
- Data Connectors3-pin and 5-pin XLR
- ConsumableIsopropyl alcohol, Isopar-G
- Net weight50 kg
- Gross weight71.5 kg
- Machine dimensions700 × 458 × 425.4 mm
- Flight case Dimensions835 × 520 × 583 mm
- Packing dimensions930 × 615 × 565 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
DH-2.4 datasheet
| Model | DH-2.4 |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Breaker |
| Breaker | 10 A, 250 V |
| Total power consumption | 2,500 W |
| Fluid tank capacity | 30 L |
| Pump Output | Approx. 15 L/min |
| Max. Supported Flame heads | 4 pcs |
| Working Mode | Fueling /Pressurize |
| Consumable | Isopropyl alcohol, Isopar-G |
| Machine dimensions | 700 × 458 × 425.4 mm |
| Flight case Dimensions | 835 × 520 × 583 mm |
| Power Input Connector | Lockable PowerCon |
| On-device control | LCD control board |
| Wireless control | No |
| Control protocol | DMX-512 |
| DMX channels | 6 |
| Data Connectors | 3-pin and 5-pin XLR |
| Net weight | 50 kg |
| Gross weight | 71.5 kg |
| Packing dimensions | 930 × 615 × 565 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against DH-2.4. Full datasheets are one click away.
| Specification |  DH-2.4This model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the DH-2.4 does on your stage
30 L fuel tank
30 L fuel tank.
Support 4 flame machines
Support 4 flame machines.
Remote control
Remote fuel and pressure supply.
Configured with pressure and fuel
Configured with pressure and fuel level monitoring.
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
DH-2.4 — quick answers
What voltage does the DH-2.4 require?
The Tcpumper accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the DH-2.4 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the DH-2.4?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
