Product demo
MODEL DFZ-800
1,200 W Haze Machine
A 1,200 W Haze Machine with 6,000 cuft/min output, 3 L tank, 11 kg / 24.3 lb. net weight.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeFuse (F)
- Breaker8 A, 250 V
- Total power consumption1,200 W
- Operating Current5.2
- Power Input ConnectorIEC
- Heat-up timeApprox. 50 s
- Heater TypeFast Coil Heater
- Fluid tank capacity3 L
- Adjustable outputYes
- Volume Adjustment Level/Range1–100%
- Max output volumeApprox. 6,000 cuft/min
- Fluid Consumption @ full volumeApprox. 8.0 mL/min
- Maximum Continuous Duration @ full volumeUnlimited
- Continuous OutputYes
- Max continuous output level100%
- Fully-loaded Cumulative Output Duration @ full volumeApprox. 437 min
- Consumable Type for Standard Output TestPRO-C/PRO-J
- On-device controlLCD control board
- Wireless controlW-4 / RF 433MHz / Built-in
- Wired controlNo
- Control protocolDMX-512
- DMX channels2
- Data Connectors3- and 5-pin XLR
- Power CordYes
- Wireless Controller ModelW-4 / RF 433MHz / Transmitter
- Wired Controller ModelNo
- ConsumablePRO-C or PRO-J Haze Fluid
- Net weight11 kg / 24.3 lb.
- Gross weight13 kg / 28.7 lb.
- Machine dimensions313 × 310 × 255 mm / 12.3 × 12.2 × 10
- Packing dimensions445 × 445 × 410 mm / 17.5 × 17.5 × 16.1
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
DFZ-800 datasheet
| Model | DFZ-800 |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Fuse (F) |
| Breaker | 8 A, 250 V |
| Total power consumption | 1,200 W |
| Heat-up time | Approx. 50 s |
| Heater Type | Fast Coil Heater |
| Fluid tank capacity | 3 L |
| Adjustable output | Yes |
| Volume Adjustment Level/Range | 1–100% |
| Max output volume | Approx. 6,000 cuft/min |
| Fluid Consumption @ full volume | Approx. 8.0 mL/min |
| Maximum Continuous Duration @ full volume | Unlimited |
| Continuous Output | Yes |
| Max continuous output level | 100% |
| Fully-loaded Cumulative Output Duration @ full volume | Approx. 437 min |
| Consumable Type for Standard Output Test | PRO-C/PRO-J |
| Power Cord | Yes |
| Consumable | PRO-C or PRO-J Haze Fluid |
| Machine dimensions | 313 × 310 × 255 mm / 12.3 × 12.2 × 10 |
| Power Input Connector | IEC |
| On-device control | LCD control board |
| Wireless control | W-4 / RF 433MHz / Built-in |
| Wired control | No |
| Control protocol | DMX-512 |
| DMX channels | 2 |
| Data Connectors | 3- and 5-pin XLR |
| Wireless Controller Model | W-4 / RF 433MHz / Transmitter |
| Wired Controller Model | No |
| Operating Current | 5.2 |
| Net weight | 11 kg / 24.3 lb. |
| Gross weight | 13 kg / 28.7 lb. |
| Packing dimensions | 445 × 445 × 410 mm / 17.5 × 17.5 × 16.1 |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against DFZ-800. Full datasheets are one click away.
| Specification |  DFZ-800This model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the DFZ-800 does on your stage
Output performance
Continuous output even and light haze.
Super quiet
Super quiet.
Heating system
New and fast heater.
Heating system
New heating system, only 50 seconds heat-up time.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
DFZ-800 — quick answers
What voltage does the DFZ-800 require?
The 1,200 W Haze Machine accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the DFZ-800 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the DFZ-800?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
