MODEL DFZ-4000C
Wave Haze Machine
A Wave Haze Machine with 2,600 W power, 33,000 cuft/min output, 8 m throw.
- Input voltageAC 220–240 V, 50/60 Hz
- Breaker typeBreaker
- Breaker15 A, 250 V
- Total power consumption2,600 W
- Heat-up timeApprox. 7 min
- Fluid tank capacity5 L X 2
- Adjustable outputYes
- Max output volumeApprox. 33,000 cuft/min
- Max output distanceApprox. 8 m
- Fluid consumptionApprox. 10.5 min/L
- Maximum Continuous DurationApprox. 70 S
- HorizontalYes
- UpstandNo
- SidelongNo
- Hang Upside DownNo
- Rigging & TrussingNo
- On-device controlYes
- Wireless controlNo
- Wired controlNo
- Control protocolDMX512
- DMX channels2
- ConsumablePRO-C or PRO-A
- Net weight58.5 kg
- Gross weight63 kg
- Machine dimensions754 × 478 ×747 mm
- Packing dimensions800 × 526 ×795 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
DFZ-4000C datasheet
| Model | DFZ-4000C |
| Input voltage | AC 220–240 V, 50/60 Hz |
| Breaker type | Breaker |
| Breaker | 15 A, 250 V |
| Total power consumption | 2,600 W |
| Heat-up time | Approx. 7 min |
| Fluid tank capacity | 5 L X 2 |
| Adjustable output | Yes |
| Max output volume | Approx. 33,000 cuft/min |
| Max output distance | Approx. 8 m |
| Fluid consumption | Approx. 10.5 min/L |
| Maximum Continuous Duration | Approx. 70 S |
| Horizontal | Yes |
| Upstand | No |
| Sidelong | No |
| Hang Upside Down | No |
| Rigging & Trussing | No |
| Consumable | PRO-C or PRO-A |
| Machine dimensions | 754 × 478 ×747 mm |
| On-device control | Yes |
| Wireless control | No |
| Wired control | No |
| Control protocol | DMX512 |
| DMX channels | 2 |
| Net weight | 58.5 kg |
| Gross weight | 63 kg |
| Packing dimensions | 800 × 526 ×795 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against DFZ-4000C. Full datasheets are one click away.
| Specification |  DFZ-4000CThis model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | AC 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the DFZ-4000C does on your stage
Output performance
Integrated flight case, compact volume, compact size, applicable for shipping.
Fan system
With quiet fan, haze output is quieter.
Output performance
Manually adjustable angle baffle, can control the angle of fog output.
Send billows of smoke
Send billows of smoke evenly and quickly over a wide space.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
DFZ-4000C — quick answers
What voltage does the DFZ-4000C require?
The Wave Haze Machine accepts AC 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the DFZ-4000C with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the DFZ-4000C?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
