Product demo
MODEL DFZ-2100
1,200 W Haze Machine
A 1,200 W Haze Machine with 12,000 cuft/min output, 5 L tank, 14 kg / 30.9 lb. net weight.
- Input voltage220–240 V, 50/60 Hz
- Breaker typeBreaker
- Breaker8 A, 250 V
- Total power consumption1,200 W
- Operating Current5.2
- Power Input ConnectorHard-wired
- Heat-up timeApprox. 50 s
- Heater TypeFast Coil Heater
- Fluid tank capacity5 L
- Adjustable outputYes
- Volume Adjustment Level/Range1–100%
- Max output volumeApprox. 12,000 cuft/min
- Fluid Consumption @ full volumeApprox. 83 min/L
- Maximum Continuous Duration @ full volumeUnlimited
- Continuous OutputYes
- Max continuous output level100%
- Fully-loaded Cumulative Output Duration @ full volumeApprox. 416 min
- Consumable Type for Standard Output TestPRO-C/PRO-J
- On-device controlLCD control board
- Wireless controlNo
- Wired controlNo
- Control protocolDMX-512
- DMX channels2
- Data Connectors3- and 5-pin XLR
- Flight CaseYes
- Power CordYes
- Wireless Controller ModelNo
- Wired Controller ModelNo
- ConsumablePRO-C or PRO-J Haze Fluid
- Net weight14 kg / 30.9 lb.
- Gross weight16 kg / 35.3 lb.
- Machine dimensions510 × 390 × 265 mm / 20.1 × 15.4 × 10.4
- Packing dimensions590 × 475 × 335 mm / 23.2 × 18.7 × 13.2
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
DFZ-2100 datasheet
| Model | DFZ-2100 |
| Input voltage | 220–240 V, 50/60 Hz |
| Breaker type | Breaker |
| Breaker | 8 A, 250 V |
| Total power consumption | 1,200 W |
| Heat-up time | Approx. 50 s |
| Heater Type | Fast Coil Heater |
| Fluid tank capacity | 5 L |
| Adjustable output | Yes |
| Volume Adjustment Level/Range | 1–100% |
| Max output volume | Approx. 12,000 cuft/min |
| Fluid Consumption @ full volume | Approx. 83 min/L |
| Maximum Continuous Duration @ full volume | Unlimited |
| Continuous Output | Yes |
| Max continuous output level | 100% |
| Fully-loaded Cumulative Output Duration @ full volume | Approx. 416 min |
| Consumable Type for Standard Output Test | PRO-C/PRO-J |
| Flight Case | Yes |
| Power Cord | Yes |
| Consumable | PRO-C or PRO-J Haze Fluid |
| Machine dimensions | 510 × 390 × 265 mm / 20.1 × 15.4 × 10.4 |
| Power Input Connector | Hard-wired |
| On-device control | LCD control board |
| Wireless control | No |
| Wired control | No |
| Control protocol | DMX-512 |
| DMX channels | 2 |
| Data Connectors | 3- and 5-pin XLR |
| Wireless Controller Model | No |
| Wired Controller Model | No |
| Operating Current | 5.2 |
| Net weight | 14 kg / 30.9 lb. |
| Gross weight | 16 kg / 35.3 lb. |
| Packing dimensions | 590 × 475 × 335 mm / 23.2 × 18.7 × 13.2 |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against DFZ-2100. Full datasheets are one click away.
| Specification |  DFZ-2100This model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | 220–240 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the DFZ-2100 does on your stage
Output performance
Continuous output, even and light haze.
Output performance
12,000cfm output, 0-100% precisely adjustable.
Fluid system
Nozzle free from fluid squirting.
Fan system
Independent variable haze and fan control.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
DFZ-2100 — quick answers
What voltage does the DFZ-2100 require?
The 1,200 W Haze Machine accepts 220–240 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the DFZ-2100 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the DFZ-2100?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
