Product demo
MODEL D-V3
Cold spark machine
A Cold spark machine with 5 m throw, DMX512 2-channel control, 3.6 kg net weight.
- Input voltageAC 100–120 V, 50/60 Hz
- Breaker typeBreaker
- Breaker8 A, 250 V
- Nominal Total Power Consumption450 W
- Heat-up timeApprox. 4 min 30 s
- Powder Tank Capacity255 g
- Max output distanceApprox. 5 m
- Maximum output powder consumptionApprox. 8.5 g
- Max continuous output30 S
- Continuous OutputRe-operate the machine every 30 seconds to spray spark
- Power CordYes
- Wireless Controller ModelW-7
- HorizontalYes
- Inclined15°
- Side-wayNo
- Upside DownNo
- Rigging & TrussingNo
- Rotating NozzleNo
- DeflectorNo
- On-device controlLCD control board
- Wireless controlW-7
- Wired controlNo
- Control protocolDMX-512
- DMX channels2
- Rfid CardNo
- Net weight3.6 kg
- Gross weight4.2 kg
- Machine dimensions195 × 195 × 249 mm
- Packing dimensions251 × 251 × 285 mm
Sample orders from 1 pieceStandard models ship in 15–30 days48-hour aging test1-year warrantyCE & RoHSOEM / ODM welcome
We reply within one business day (GMT+8). WhatsApp is the fastest channel.
Full Specifications
D-V3 datasheet
| Model | D-V3 |
| Input voltage | AC 100–120 V, 50/60 Hz |
| Breaker type | Breaker |
| Breaker | 8 A, 250 V |
| Nominal Total Power Consumption | 450 W |
| Heat-up time | Approx. 4 min 30 s |
| Powder Tank Capacity | 255 g |
| Max output distance | Approx. 5 m |
| Maximum output powder consumption | Approx. 8.5 g |
| Max continuous output | 30 S |
| Continuous Output | Re-operate the machine every 30 seconds to spray spark |
| Power Cord | Yes |
| Horizontal | Yes |
| Inclined | 15° |
| Side-way | No |
| Upside Down | No |
| Rigging & Trussing | No |
| Rotating Nozzle | No |
| Deflector | No |
| Rfid Card | No |
| Machine dimensions | 195 × 195 × 249 mm |
| Wireless Controller Model | W-7 |
| On-device control | LCD control board |
| Wireless control | W-7 |
| Wired control | No |
| Control protocol | DMX-512 |
| DMX channels | 2 |
| Net weight | 3.6 kg |
| Gross weight | 4.2 kg |
| Packing dimensions | 251 × 251 × 285 mm |
Compare with
Side-by-side specifications
Pick up to 3 models to compare against D-V3. Full datasheets are one click away.
| Specification |  D-V3This model |  H-K1Pro Auto Smoke Ring Machine |  H-1 PLUS2-in-1 Moving-Head Fog Jet |
|---|---|---|---|
| Type | — | Auto smoke ring machine | Moving head super-jet fog machine |
| Light source | — | RGB 3-in-1 LED ring | 24 × 5 W, RGBA |
| Control protocol | DMX-512 | DMX512, 3 channels | DMX-512, 10 channels |
| Input voltage | AC 100–120 V, 50/60 Hz | AC 220–240 V, 50/60 Hz | 220–240 V, 50/60 Hz |
See it in action
Product demo
Features
What the D-V3 does on your stage
Rugged housing
High Flame-Retardant Housing: V-0 grade flame-retardant materials, lightweight, safe, and durable.
Power
Powerful Performance: high-speed brush-less motor for higher and denser spark.
Dual-convection cooling: enhances stability
Dual-convection cooling: enhances stability and heat dissipation.
Heating system
Intelligent Heating Technology: ensures extended stable operation.
Applications & Downloads
Where it works
Accessorize the rig
In the box & often bought together
After-sales & warranty
Backed before and after the show
1-year warranty
Fixtures carry a 1-year warranty; per-model terms are stated in your quotation and order confirmation.
Spare modules stocked
We stock spare modules for all current models — ship them with future orders or separately by express.
Remote technical support
DMX mapping advice, programming help and repair guidance by video call, on WhatsApp or email.
48-hour aging test
Every unit passes a 48-hour aging test and full-function inspection before packing.
Full purchasing, OEM and after-sales answers in the FAQ.
Good to know
D-V3 — quick answers
What voltage does the D-V3 require?
The Cold spark machine accepts AC 100–120 V, 50/60 Hz. We build for export markets — tell us your target market in the inquiry and we confirm the matching power configuration before dispatch.
Can I order the D-V3 with my own logo (OEM/ODM)?
Yes — logo, startup screen, nameplate and packaging are the most common OEM requests. Send your artwork and we confirm the mock-up before production.
How fast can I get a sample of the D-V3?
Sample orders start from 1 piece. Standard models usually ship within 15–30 days depending on model and quantity, and every unit passes a 48-hour aging test before packing.
